Prepared By:

Review not requested

Dana Flora-Adams
Tracking Data Delivery Service CDE



 Date

Reviewed By:

Review not requested

Dana Flora-Adams
Tracking Data Delivery Service CDE



 Date Review not requested

Ana Guerrero
Manager, DDOSO Telemetry, Tracking, and
Command End to End Data Office



 Date
Review not requested

Richard D. Benson
Telecommunications & Mission System Manager



 Date Review not requested

Eugene Burke
Telecommunications & Mission System Manager



 Date
Review not requested

Daniel F. Finnerty
Telecommunications & Mission System Manager



 Date Review not requested

Dwight P. Holmes
Telecommunications & Mission System Manager



 Date
Review not requested

Andrew Kwok
Telecommunications & Mission System Manager



 Date Review not requested

Peter T. Poon
Telecommunications & Mission System Manager



 Date
Review not requested

Stefan Waldherr
Telecommunications & Mission System Manager



 Date Review not requested

Byron G. Yetter
Telecommunications & Mission System Manager



 Date

Review not requested

Richard Machuzak
System Engineer for Observational Data`



 Date

Review not requested

Sami Asmar
Radio Science Systems Group



 Date
Review not requested

James Border
VLBI Subsystem Engineer

Date Review not requested

Tomas Martin-Mur
MGSS Navigation and Mission Design Manager



 Date
Review not requested

Michael Stoloff
TTC&DM Telemetry and Tracking
Subsystem SE



 Date

This page is intentionally left blank.

Change Log

Rev. Check if Minor Rev. Issue Date Affected Sections Change Summary
04/30/2000 All This is a new document.
A 05/31/2002 All Updated data blocks, added/corrected text descriptions
B 12/15/2002 Sections 1, 2 and 3, Appendix A and B Corrected typos, added file header description (Appendix B)
C 09/15/2003 Section 3 and Appendix A Updated with additional parameters, simplified Data Type 6, and corrected errors.
D 11/02/2004 Sections 1, 2 and 3, Appendix A Updated Secondary CHDO 135, updated VLBI CHDO, add invalid/unknown to ul_assembly_num in CHDO 132, added enumerations to ramp_type in DT9 and corrected typos.
E 05/15/2005 Section 3 Updated Tone Range CHDO and corrected typos.
F 08/31/2005 Section 3, Appendix A Updated Doppler Count CHDO and corrected typos. Added Note number 89.
G 03/15/2006 Appendix B Updated file name format adding DSS ID.
H 07/31/2006 Section 1.2, Appendix A Typo in the Signal Level equation (Note 58).
I 09/29/2006 Sections 1, 3 and Appendix A Clarified the definition of data type in sections 1.6.1 and 3.1.3, Updated Uplink and Downlink PN Ranging Phase CHDOs and updated Note 34. Table 3-1
J 05/31/2007 Sections 1, 3 and Appendix A Updated Downlink and Derived Secondary headers adding LNA correction value. Updated Downlink Sequential and Downlink PN Ranging Phase Data CHDOs, adding station calibration correction flag. Updated (reused) Note number 9.
J-1 X 02/29 /2008 Section 1 Minor changes to update footer tags, change ‘DSMS’ to ‘DSN’, edit Section 1 sequence

This page is intentionally left blank.

Contents

Section Page

Section 1 Introduction........................................................................................................ 1-1

1.1 Purpose and Scope...........................................................................................................1-1

1.2 Effectivity ........................................................................................................................1-1

1.3 Revision and Control .......................................................................................................1-1

1.4 Relationship to Other Documents....................................................................................1-1

1.5 Notation and Conventions ...............................................................................................1-2

1.5.1 Terminology .......................................................................................................1-2

1.5.2 Conventions ........................................................................................................1-3

1.6 References........................................................................................................................1-5

1.7 Abbreviations...................................................................................................................1-6

Section 2 Functional Overview.......................................................................................... 2-1

2.1 General Description.........................................................................................................2-1

2.2 Operational Concept........................................................................................................2-1

2.3 Equipment........................................................................................................................2-1

Section 3 Detailed Interface Description..........................................................................3-1

3.1 Data Definition ................................................................................................................3-1

3.1.1 Tracking Data SFDU Label................................................................................3-2

3.1.2 Aggregation CHDO Label..................................................................................3-4

3.1.3 Primary CHDO...................................................................................................3-5

3.1.4 Secondary CHDOs..............................................................................................3-6

3.1.5 Tracking Data CHDOs......................................................................................3-32

3.2 Dependencies.................................................................................................................3-98

Appendix A Notes............................................................................................................... A-1

Appendix B File Format .....................................................................................................B-1

B.1 LVO Structure of Files.........................................................................................................B-1

B.2. Physical Layout of Files......................................................................................................B-1

Figures

Figure Page

Figure 3-1. LVO Structure of the Tracking Data SFDU...........................................................................3-1
Figure 3-2. Physical Layout of the Tracking Data SFDU.........................................................................3-2
Figure B-1. LVO Structure of Files ......................................................................................................... B-1
Figure B-2. File Layout............................................................................................................................ B-2
Figure B-3. Sample Header of File .......................................................................................................... B-3

Tables

Table Page

Table 3-1. Tracking SFDU Label Definitions ..........................................................................................3-2
Table 3-2. Aggregation CHDO Label Definitions....................................................................................3-5
Table 3-3. Primary CHDO Definitions.....................................................................................................3-5
Table 3-4. Secondary CHDO 134 Definitions..........................................................................................3-7
Table 3-5. Secondary CHDO 132 Definitions........................................................................................3-14
Table 3-6. Secondary CHDO 133 Definitions........................................................................................3-17
Table 3-7. Secondary CHDO 135 Definitions........................................................................................3-23
Table 3-8. Secondary CHDO 136 Definitions........................................................................................3-27
Table 3-9. Uplink Carrier Phase CHDO (Data Type 0) Definitions........................................................3-33
The Uplink Sequential Ranging Phase CHDO is defined in Table 3-10.................................................3-36
Table 3-10. Uplink Sequential Ranging Phase CHDO (Data Type 2) Definitions..................................3-36
Table 3-11. Uplink PN Ranging Phase CHDO (Data Type 4) Definitions..............................................3-39
Table 3-12. Ramp CHDO (Data Type 9) Definitions..............................................................................3-44
Table 3-13. Downlink Carrier Phase CHDO (Data Type 1) Definitions.................................................3-46
Table 3-14. Downlink Sequential Ranging Phase CHDO (Data Type 3) Definitions.............................3-53
Table 3-15. Downlink PN Ranging Phase CHDO (Data Type 5) Definitions.........................................3-60
Table 3-16. Doppler Count CHDO (Data Type 6) Definitions................................................................3-68
Table 3-17. Sequential Range CHDO (Data Type 7) Definitions ...........................................................3-71
Table 3-18. Angle CHDO (Data Type 8) Definitions..............................................................................3-77
Table 3-19. DRVID CHDO (Data Type 11) Definitions.........................................................................3-79
Table 3-20. PN Range CHDO (Data Type 14) Definitions.....................................................................3-80
Table 3-21. Tone Range CHDO (Data Type 15) Definitions..................................................................3-87
Table 3-22. Carrier Frequency Observables CHDO (Data Type 16) Definitions....................................3-88
Table 3-23. Total Count Phase Observable CHDO (Data Type 17) Definitions.....................................3-90
Table 3-24. VLBI CHDO (Data Type 10) Definitions............................................................................3-93
Table 3-25. Smoothed Noise CHDO (Data Type 12) Definitions...........................................................3-95
Table 3-26. Allan Deviation CHDO (Data Type 13) Definitions............................................................3-97
Table B-1. Primary SFDU Label ............................................................................................................. B-3
Table B-2. K-Header (or K-Object) SFDU Label.................................................................................... B-5
Table B-3. Catalog Information (Value Field of the K-Object)............................................................... B-6
Table B-4. I-Object SFDU Label.............................................................................................................B-8

Section 1
Introduction

1.1 Purpose and Scope

This module specifies the format and content of radio metric tracking data delivered to navigation and radio science customers from the Telecommunications Services. The method of delivery of the data is outside the scope of this document.

TRK-2-34 is essentially a consolidation of the data that are currently contained in the TRK-2-18, TRK-2-20, and TRK-2-30 products delivered to customers.

1.2 Effectivity

Revision JI-1 provides editorial updates only and supersedes Revision J

Revision JThis release updates secondary CHDOs 133 and 134 adding LNA correction value (lna_corr_value); Downlink Sequential Ranging Phase and Downlink PN Ranging Phase Data CHDOs adding station calibration correction flag; and Appendix A, updating note number 9.

Certain parameters may not be available in initial TRK-2-34 output. These parameters will be marked as invalid (using validity flags) in the data or not delivered in the case of certain data types, such as Allan Deviation (DT13) and Smoothed Noise (DT12).

1.3 Revision and Control

Revisions or changes to the information herein presented may be initiated according to the procedure specified in the Introduction to Document 820-013.

Documents controlling this version include

[1] DSN 813-109, D-17818    Preparation Guidelines and Procedures for Deep Space Mission System (DSMS) Interface Specifications (DSNMS internal document, for reference only.)
[2] DSN 820-013, Module 0171-Telecomm-NJPL   DSMS External Interface Specification—DSMS Created SFDU Structures

1.4 Relationship to Other Documents

TRK-2-34 replaces TRK-2-25 as the archival format. TRK-2-20 and TRK-2-30 will continue to be available to the customers.

1.5 Notation and Conventions

1.5.1 Terminology

Many of the terms used in this module are taken from the literature describing the Standard Formatted Data Unit (SFDU) concept (e.g., Reference [2] Reference [5]). The SFDU concept was developed by the Consultative Committee for Space Data Systems (CCSDS) to provide a standardized and internationally recognized methodology for information interchange. Because the SFDU concept evolved over time, the meaning of some terms has evolved. The definitions provided herein are intended to clarify the use of certain terms as they apply to this module:

a) The term ASCII refers to the American Standard Code for Information Interchange, a seven-bit code for representing letters, digits, and symbols which has been standardized by the American National Standards Institute (Reference [7]). This code has been incorporated into the ISO code of the same nature (Reference [8]) which includes other symbols and alphabets. Since the ISO code is an eight-bit code, the ASCII code is embedded in an eight-bit field in which the most significant bit is set to zero. In this module, ASCII always refers to the seven-bit ASCII code embedded, as described, in an eight-bit field. When applied to a multi-byte field, it implies that each byte in the field contains an ASCII code.

b) The term restricted ASCII (RA) refers to the subset of ASCII consisting of the codes for the twenty-six upper-case letters (‘A’-‘Z’) and the ten decimal digits (‘0’-‘9’). When applied to a multi-byte field, it implies that each byte in the field contains an RA code.

c) A label-value-object (LVO) is a data structure that is comprised of a label field and a value field. The label field provides for the data structure to be self-identifying and self-delimiting. The value field contains user-defined data in any format. The LVOs themselves are made up of a sequence of bytes. In this module, LVO is used in a generic sense to refer to any data structure with these attributes.

d) An LVO may be a simple LVO or a compound LVO. If the value field of the LVO contains purely user data, it is a simple LVO. If the value field of the LVO contains purely LVOs, it is a compound LVO. The value field of a compound LVO consists of a sequence of one or more LVOs, each of which can be a simple or compound LVO itself.

e) A standard formatted data unit (SFDU) is an LVO that conforms to a defined set of structure and construction rules, namely the specification in Reference [2]the specification in Reference [5]. Unfortunately, the two specifications are slightly different, leading to two different definitions of what an SFDU is. The term DSN tracking SFDU (or, more simply, tracking SFDU) refers to the SFDU defined and controlled by this module. The DSN tracking SFDU conforms to the structure and construction rules specified in Reference [2]. It does not strictly conform to the internationally recognized SFDU structure and construction rules recommended by CCSDS in Reference [5].

f) A compressed header data object (CHDO), as defined in Reference [2]s an LVO. Its design is modeled on the SFDU concept, but a CHDO is not an SFDU. The CHDO derives its name from the fact that the label field of a CHDO is considerably shorter than the label field of an SFDU (four bytes instead of twenty). The CHDO provides a means of structuring user data with less overhead than would be required if an SFDU were used. However, with respect to SFDU structure and construction rules, a CHDO (or a sequence of CHDOs) is merely user data contained in the value field of an SFDU.

g) The term type attribute is used to refer to the subfield(s) of an LVO label field that affect the self-identifying property of the LVO. Within the applicable domain, the type attribute is a unique reference to a description of the format and meaning of the data contained in the value field of the LVO.

h) All of the LVOs described in this module contain a length attribute in their label field. The length attribute is a subfield of the LVO label field; it contains the length, in bytes, of the value field of the LVO. When interpreted in the context of the structure and construction rules specified in Reference [2], the length attribute affects the self-delimiting property of the LVO. The use of a length attribute is not the only means by which an LVO can be self-delimiting; Reference [5], for example, provides several mechanisms that do not rely on an explicit length.

i) The term data type is used to distinguish between different types of SFDUs. A data type is uniquely identified by its record id, which is an aggregation of four fields: major data class, minor data class, mission id and format code.

1.5.2 Conventions

The following conventions are used in this module:

a) LVOs are defined as being made up of a sequence of eight-bit bytes, so data structures in this module are illustrated as a sequence of bytes. All data structures defined in this module must be an even number of bytes in length. Given a data structure that is N bytes in length, the first byte in the structure is drawn in the most top justified position and is identified as “byte 0.” The following byte is identified as “byte 1” and so on, to “byte N-1” which is drawn in the most bottom justified position. Within each byte, the most significant bit is drawn in the most left justified position and is identified as “bit 1.” The next most significant bit is identified as “bit 2” and so on, to “bit 8” which is drawn in the most right justified position. Any bit in a data structure is uniquely identified by specifying the byte within which it occurs and its position within that byte (e.g., “byte 5, bit 8”).

b) Data structures are divided into fields, where a field is a sequence of bits. Fields are identified by specifying the starting and ending bits of the field. For fields that cross byte boundaries, bit 8 of byte M is more significant than, and is immediately followed by, bit 1 of byte M+1. A field may be divided into subfields in a similar manner.

c) Several conventions for expressing the length of a data structure, or a part of a data structure, are used in this module. The length attribute of an LVO is always given in bytes and always refers to the length of the value field of the LVO (i.e., excluding the label field).

d) In the data structure descriptions in this module, many fields are defined to contain a numerical value. Several different formats for expressing numbers are used, as follows:

1) Unsigned integer. An integer number is expressed in binary, using all bits of the field as necessary. Negative quantities cannot be expressed. For an n-bit field, the range of values that can be represented is from 0 to 2n-1. The number of bytes in the unsigned integer (m) is represented by a “-m” after the format statement.

2) Integer. An integer number is expressed in binary, using two's complement notation. For an n-bit field, the range of values that can be represented is from -2n-1 to 2n-1-1. The number of bytes in the integer (m) is represented by a “m” after the format statement.

3) Restricted ASCII. Each decimal digit of an integer number is expressed by its corresponding RA code. The field must be an integral number of bytes in length. For multi-digit fields, the first byte of the field contains the most significant digit, the second byte contains the next most significant digit, and so on. If the number of digits is less than the number of bytes in the field, leading zeroes are used to fill the field. Negative quantities cannot be expressed. In an n-byte field, the range of values that can be represented is from 0 to 10n-1. The number of bytes in the Restricted ASCII string (m) is represented by a “-m” after the format statement.

4) IEEE Single. A 32-bit, single precision, IEEE floating point-format is used to express real numbers. Single precision floating-point numbers are expressed in the ANSI/IEEE standard (Reference [6]) single precision format with a sign bit, 8-bit exponent, and 23-bit mantissa.

5) IEEE Double. A 64-bit, double precision, IEEE floating-point format is used to express real numbers. Double precision floating-point numbers are expressed in the ANSI/IEEE (Reference [6]) standard double precision format with a sign bit, 11-bit exponent, and 52-bit mantissa.

e) For fields defined to contain a constant value, the constant value will be enclosed in single quotes (e.g., ‘2’) if the information is expressed in RA, and not so enclosed (e.g., 2) if the information is expressed in binary.

f) Unless explicitly stated otherwise, fields defined as “reserved” are to be set to binary zero by the originator, and are to be ignored by the recipient.

g) Time tags are in UTC, as received from the Frequency and Timing Subsystem (FTS) of the DSN:

  • 00:00:00 is second 0.0.

  • 23:59:59 is second 86399.0.

  • Leap second is 86400.0.

h) The term "UPL-DTT antenna" refers to antennas that have UPL and DTT equipment (currently 34m HEF, 34m BWG, and 70m antennas). The term "non-UPL-DTT antenna" refers to antennas that do not have this equipment (currently 26m antennas and DSS-27).

1.6 References

Documents
[3] DSN 820-013, D-16765 DSN External Interface Specification
[3a] DSN 820-013, Module OPS-6-21 DSN External Interface Specification -Standard Code  Assignments
[3b] DSN 820-013, Module 0172-Telecomm-CHDO DSN External Interface Specification – JPL Created CHDO Structures
[3c] DSN 820-013 Module TRK-2-18 DSN External Interface Specification – Tracking System Interfaces Orbit Data File Interface
[3d] DSN 820-013  Module TRK-2-20 DSN System Requirements Detailed Interface Design - DSN Tracking System Universal Tracking Data Interface
[3e] DSN 820-013 Module TRK-2-30 DSN System Requirements Detailed Interface Design – DSN Tracking System DSN Tracking Data Interface
[4] CCSDS 620.0-B-2 CCSDS Recommendation for Space Data System Standards— Standard Formatted Data Units—Structure and Construction Rules (Issue 2, May 1992)
[5] ANSI T-49-12 ANSI/IEEE STD 754-1985—IEEE Standard for Binary Floating-Point Arithmetic
[6] ANSI X3.4-1986 (R1997) Information Systems - Coded Character Sets - 1 Bit American National Standard Code for Information Interchange (7-Bit ASCII)
[7] ISO/IEC 646-1991 Information Technology - ISO 7-bit Coded Character Set for Information Interchange
[8] DSN 810-047 DSN Antenna and Facility Identifiers (DSN internal document, for reference only.)



Web Sites:

[3] DSN 820-013, D-16765  DSN External Interface Specification http://jaguar.jpl.nasa.gov

1.7 Abbreviations

Abbreviations used in this document are defined with the first textual use of the term. Abbreviations appearing in this module are:

ADID   Authority and Description Identifier
AMMOS   Advanced Multi-mission Operations System
ASCII   American Standard Code for Information Exchange
ANSI   American Nation Standards Institute
CHDO   Compressed Header Data Object
CCSDS   Consultative Committee for Space Data Systems
dB   decibel
dBm   decibels above the reference level of 1 milliWatt
deg   degrees
DOD   Differential One-way Doppler
DOR Differential One-way Ranging
DSS Deep Space Station
DTK DSCC Tracking Subsystem
DTT   Downlink Telemetry and Tracking Subsystem
EOF   End of File
FFT   Fast Fourier Transform
FOM   Figure of Merit
FSP   Full Spectrum Processing Subsystem
FTS   Frequency and Timing Subsystem
Hz   Hertz
ID   Identifier
IEEE   Institute of Electrical and Electronics Engineers
IF   Intermediate Frequency
JPL   Jet Propulsion Laboratory
K   Kelvin
LCP   Left Hand Circular Polarization
LNA   Low Noise Amplifier
LVO   Label Value Object
MDA    Metric Data Assembly
MFR    MultiFunction Receiver
MPA   Metric Pointing Assembly
MTA   Metric Tracking Assembly
N/A    Not Applicable
NASA   National Aeronautics and Space Administration
NOCC   Network Operations Control Center
NSP    Network Simplification Project
NVP    NOCC VLBI Processor Subsystem
PN    Pseudo-Noise
RA    Restricted ASCII
RCP    Right Hand Circular Polarization
RF    Radio Frequency
RMDC   Radio Metric Data Conditioning
RTLT    Round-Trip Light Time
RU    Range Unit
Sec    seconds
SFDU    Standard Formatted Data Unit
SNT    System Noise Temperature
UPL    Uplink Tracking and Command Subsystem
UTC    Universal Time Coordinated
VLBI    Very Long Baseline Interferometry
W    Watts

This page intentionally left blank.

Section 2
Functional Overview

2.1 General Description

Radio metric data received from the DSCCs will be processed, validated, and corrected. The resulting data will be placed into the TRK-2-34 and TRK-2-18 products. Validated/corrected data are available to customers as files, stream-type queries, or broadcast streams. The file format is described in Appendix B. .

This processing is done in the AMMOS system. It includes the software tools that are used to perform radio metric data processing, validation, correction, and visualization, and to generate the tracking data file products. The function of the processing is to process, generate, and deliver radio metric data to projects and end users to support spacecraft navigation and scientific study.

Listed below are the documents and 820-013 interface modules that define specific fields in the TRK-2-34 headers:

Reference [3a]: DSN spacecraft ID, AMMOS mission ID

Reference [8]: station ID

Reference [3b] : originator ID, last modifier ID

2.2 Operational Concept

Users provide spacecraft configuration data (such as transponder number, spacecraft oscillator frequency values, etc.) and light time data. The user also specifies data delivery options (such as data decimation rate). This data, along with the DSN physical data maintained in internal tables, are combined with the raw measurements from the DSN to generate the radiometric data described by this document.

Parameters and data types that require predicted values, such as prefit residuals and Allan deviation, will not be available if the trajectory data for generating the predicted values is not available. If this happens, the parameter status will be marked as invalid (using validity flags) and the data types will not be generated.

2.3 Equipment

All equipment used in the measurement or generation of tracking data get their frequency and timing references from the Frequency and Timing Subsystem (FTS) of the DSN.

The non-UPL-DTT antennas have a mixture of tracking equipment. The 26m subnet uses the Metric Pointing Assembly (MPA). DSS-27, a 34m antenna, uses the Metric Tracking Assembly (MTA).

Arraying at a complex is done with the Full Spectrum Processing Subsystem (FSP).

This page intentionally left blank.

Section 3
Detailed Interface Description

3.1 Data Definition

Viewed as a compound LVO, the value field of the tracking data SFDU contains two LVOs, an aggregation CHDO and a tracking data CHDO. The aggregation CHDO is a compound LVO; its value field contains two simple LVOs, a primary CHDO and a secondary CHDO. The aggregation CHDO exists solely for the purpose of allowing the primary and secondary CHDOs to be grouped together and treated as a single LVO. The value fields of the primary and secondary CHDOs contain annotation data (identification, configuration, status, and performance parameters) that pertain to the data in the tracking data SFDU. The tracking data CHDO is a simple LVO; its value field contains the actual tracking data.

Figure 3-1. LVO Structure of the Tracking Data SFDU

Figure 3-2 shows the physical layout of the tracking data SFDU. It is divided into the following sections: the tracking SFDU label, the aggregation CHDO label, the primary CHDO, the secondary CHDOs, and the tracking data CHDOs. There are five different types of secondary CHDOs, and 18 types of tracking data CHDOs.

The following sections present the detailed definition of the tracking data SFDU.

Figure 3-2. Physical Layout of the Tracking Data SFDU

3.1.1 Tracking Data SFDU Label

Bytes 0 through 19 of the tracking SFDU contain the SFDU label field. The format and content of the SFDU label are defined in Table 3-1. The concatenation of Bytes 0 through 3, and 8 through 11, constitutes the type attribute of the SFDU; in CCSDS parlance, this concatenated field is known as the Authority and Description Identifier (ADID). Bytes 12 to 19 constitute the length attribute.

Table 3-1. Tracking SFDU Label Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
control_auth_id 0 Control authority identifier. ‘NJPL’ indicates that the data description information for this SFDU is maintained and disseminated by NASA/JPL. Restricted ASCII –4 N/A ‘NJPL’
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
sfdu_version_id 4 SFDU label version ID. ‘2’ indicates that the length attribute field in bytes 12 to 19 is formatted as a binary unsigned integer. Restricted ASCII –1 N/A ‘2’
sfdu_class_id 5 SFDU class ID. ‘I’ indicates that this SFDU contains data to be used by an application process. Restricted ASCII –1 N/A ‘I’
reserve2 6 Reserved. Two bytes. Restricted ASCII –2 N/A ‘00’
data_description_id 8 Data description identifier. Uniquely identifies the data description information held by the control authority identified in the ‘Control authority identifier’ item for this type of SFDU. C123 => Uplink types C124 => Downlink types C125 => Derived types C126 => Interferometric types C127 => Filtered types Restricted ASCII –4 N/A ‘C123’, ‘C124’, ‘C125’, ‘C126’, ‘C127’
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
sfdu_length 12 Length attribute of the tracking data SFDU. Indicates the length of the data following this element. DT0 => 162 DT1 => 358 DT2 => 194 DT3 => 304 DT4 => 276 DT5 => 388 DT6 => 200 DT7 => 330 DT8 => 178 DT9 => 124 DT10 => 204 DT11 => 182 DT12 => 164 DT13 => 160 DT14 => 348 DT15 => 194 DT16 => 182 + 18 * num_obs DT17 => 194 + 22 * num_obs Unsigned Integer –8 Bytes 124, 160, 162, 164, 178, 182, 194, 200, 204, 276, 304, 348, 330, 388, 358, 182 + 18 * num_ob s, 194 + 22 * num_ob s (num_o bs < 100)

3.1.2 Aggregation CHDO Label

Bytes 20 through 23 of the tracking data SFDU contain the aggregation CHDO label field, which is described in Reference [2] and defined in Table 3-2 for convenience. The value field of the aggregation CHDO is composed of the primary CHDO and a secondary CHDO. The primary CHDO is described in Section 3.1.3. The secondary CHDOs, of which there are five types, are described in Section 3.1.4.

Table 3-2. Aggregation CHDO Label Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the aggregation CHDO. A value of 1 indicates that this CHDO is an aggregation of CHDOs Unsigned Integer –2 N/A 1
chdo_length 2 Length attribute of the aggregation CHDO. Indicates the length of the sum of the primary and secondary CHDOs. CHDO 132 => 78 CHDO 133 => 122 CHDO 134 => 136 CHDO 135 => 100 CHDO 136 => 110 Unsigned Integer –2 Bytes 78, 100, 110, 122, 136

3.1.3 Primary CHDO

Bytes 24 through 31 of the tracking SFDU contain the primary CHDO, which is defined in Reference [2] and is included inTable 3-3 for convenience. Bytes 0 through 3 are the label field. Bytes 4 through 7 are the value field. The primary specifies the mission and the data type of the tracking data contained in the SFDU.

Table 3-3. Primary CHDO Definitions

Identifier Byte Off set Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the primary CHDO. A value of 2 indicates that this CHDO is a primary CHDO. Unsigned Integer – 2 N/A 2
chdo_length 2 Length attribute of the primary CHDO. Indicates the length, in bytes, of the value field (bytes after this item) of the primary CHDO. Unsigned Integer – 2 Bytes 4
mjr_data_class 4 Major data class. A value of 6 indicates that the data in this SFDU is ground station monitor data. Unsigned Integer – 1 N/A 6
Identifier Byte Off set Item Name and Description Format Units/ Precision Range Notes
mnr_data_class 5 Minor data class. Indicates data is processed tracking data. Unsigned Integer – 1 N/A 14
mission_id 6 Mission ID. Per Reference [3a], Table 3-4. Unsigned Integer – 1 N/A 0 to 255
format_code 7 Format code. Also referred to as the data type. 0 => Uplink Carrier Phase 1 => Downlink Carrier Phase 2 => Uplink Sequential Ranging Phase 3 => Downlink Sequential Ranging Phase 4 => Uplink PN Ranging Phase 5 => Downlink PN Ranging Phase 6 => Doppler 7 => Sequential Ranging 8 => Angles 9 => Ramps 10 => VLBI 11 => DRVID 12 => Smoothed Noise 13 => Allan Deviation 14 => PN Ranging 15 => Tone Ranging 16 => Carrier Observable 17 => Total Phase Observable Unsigned Integer – 1 N/A 0 to 17

3.1.4 Secondary CHDOs

There are five types of secondary CHDOs, all of which start at Byte 32 of the tracking data SFDU. The five types are organized as follows (data type is equivalent to format code):

  • CHDO 134: Derived data types - Doppler Count (data type 6), Sequential Range (data type 7), Angles (data type 8), DRVID (data type 11), PN Range (data type 14), Tone Range (data type 15), Carrier Frequency Observable (data type 16), and Total Count Phase Observable (data type 17).

  • CHDO 132: Uplink data types - Uplink Carrier Phase (data type 0), Uplink Sequential Ranging Phase (data type 2), Uplink PN Ranging Phase (data type 4), and Ramps (data type 9).

  • CHDO 133: Downlink data types - Downlink Carrier Phase (data type 1), Downlink Sequential Ranging Phase (data type 3), and Downlink PN Ranging Phase (data type 5).

  • CHDO 135: Interferometric data types - VLBI (data type 10).

  • CHDO 136: Filtered data types - Smoothed Noise (data type 12) and Allan Deviation (data type 13).

The secondary CHDOs are defined in Tables 3-4 through 3-8. Bytes 0 through 3 are the label field. Bytes 4 through M-1 (M being the length of the secondary CHDO) comprise the value field. The secondary CHDO contains parameters that a user might want to sort or filter on.

3.1.4.1 Secondary CHDO 134 (Derived Data Types)

Secondary CHDO 134 is used for the following derived data types (format codes): Doppler Count (data type 6), Sequential Range (data type 7), Angle (data type 8), DRVID (data type 11), PN Range (data type 14), Tone Range (data type 15), Carrier Frequency Observable (data type 16), and Total Count Phase Observable (data type 17). Secondary CHDO 134 is defined in Table 3-4.

Table 3-4. Secondary CHDO 134 Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the secondary CHDO. Unsigne d Integer –2 N/A 134
chdo_length 2 Length attribute of the secondary CHDO. Indicates the length, in bytes, of the value field (bytes after this item) of the secondary CHDO. Unsigne d Integer –2 Bytes 124
orig_id 4 Originator ID. Indicates where this SFDU was originated. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
last_modifier_id 5 Last modifier ID. Indicates where this SFDU was last modified. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
reserve1 6 Reserved. For future expansion of scft_id. Unsigne d Integer –1 N/A 0
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
scft_id 7 Spacecraft number. Per Reference [3a]. Unsigne d Integer –1 N/A 1 to 255
rec_seq_num 8 Record sequence number (RSN). Begins with zero; increments by one for each successive tracking SFDU of the same type; wraps around from 232-1 to zero. Value is reset to zero when software is restarted. Unsigne d Integer –4 N/A 0 to 232-1
year 12 Time tag year. Unsigne N/A 1958 to
d Integer 3000
–2
doy 14 Time tag day of year. Unsigne N/A 1 to 366
d Integer
–2
sec 16 Time tag seconds of day. IEEE Double Seconds / 0.01 sec 0.00 to 86,400.99 1
rct_day 24 Record creation time days. Days since 1/1/1958. Unsigne d Integer –2 Days / 1 day 0 to 216 - 1 74
rct_msec 26 Record creation time milliseconds of day. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,999 74
stn_stream_src 30 Station stream source. 1 => UPL/DTT 2 => non-UPL-DTT: TRK-2-30 3 => non-UPL-DTT: TRK-2-20 Unsigne d Integer –1 N/A 1 to 3
ul_band 31 Uplink frequency band. 0 => unknown or not applicable 1 => S-band Unsigne d Integer -1 N/A 0 to 5 79
2 => X-band
3 => Ka-band
4 => Ku-band
5 => L-band
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
ul_assembly_num 32 Uplink Assembly Number. Note that this is to allow for potential future cases where there might be more than one uplink of the same band at the same antenna. 0 => Unknown/Not applicable 1 => S-/X-band uplink 2 => Ka-band uplink Unsigne d Integer –1 N/A 0 to 2 79
transmit_num 33 Transmitter number. Value depends on transmitter used. A value of 0 means that the number is unknown or not applicable. Unsigne d Integer –1 N/A 0 to 3 79
transmit_stat 34 Transmit Status. 0 => not transmitting out the horn 1 => transmitting out the horn 2 => invalid or unknown Unsigne d Integer –1 N/A 0 to 2 79
transmit_mode 35 Transmitter mode. 0 => low power 1 => high power 2 => invalid or unknown Unsigned Integer –1 N/A 0 to 2 79
cmd_modul_stat 36 Command modulation status. 0 => OFF 1 => ON 2 => invalid or unknown Unsigne d Integer –1 N/A 0 to 2 79
rng_modul_stat 37 Ranging modulation status. 0 => OFF 1 => ON 2 => invalid or unknown Unsigne d Integer –1 N/A 0 to 2 79
transmit_time_tag _delay 38 Transmit time tag delay. Value used to offset uplink time tag (e.g., for Goldstone Beam Waveguide antennas). A value of -1.0 indicates invalid (or not provided). IEEE Double Seconds / 0.1 nsec -1.0, 0.0 to 1.0 2, 79
ul_zheight_corr 46 Uplink Z-height correction. Value of -99.0 indicates invalid. IEEE Single Seconds / 0.1 nsec -99.0, -1.000 to 1.000 60, 72, 79
dl_dss_id 50 Downlink antenna number. Per Reference [8]. Unsigne d Integer –1 N/A 0 to 255
reserve1a 51 Reserved. Unsigne N/A 0
One byte. d Integer
–1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
dl_chan_num 52 Downlink channel number. Unsigne N/A 0 to 24
Value of 0 implies unknown. d Integer
–1
prdx_mode 53 Predicts mode. Predicts subset used by downlink channel. 0 => No Predicts 1 => One-way 2 => Two-way 3 => Three-way 4 => Unknown Unsigne d Integer –1 N/A 0 to 4
ul_prdx_stn 54 Uplink station used for predicts. Valid only if prdx_mode is 2 or 3. Per Reference [8]. A value of 0 means that the number is unknown or not valid (e.g., no uplink). Unsigne d Integer –1 N/A 0 to 255
ul_band_dl 55 Uplink frequency band assumed by downlink. Uplink band value used by downlink for turn around computations. 0 => Unknown or not applicable 1 => S-band 2 => X-band 3 => Ka-band 4 => Ku-band 5 => L-band Unsigned Integer –1 N/A 0 to 5
array_delay 56 Array delay value. Time delay added to path by arraying equipment. Obtained from arraying equipment. Any measurements include this delay. Valid only if Array Flag (array_flag) is non-zero. IEEE Double Seconds / 0.1 nsec 0.0 to 1.0 4
fts_vld_flag 64 Frequency and Timing (FTS) validity. 0 => Equipment is not synced with FTS 1 => Equipment is synced with FTS Unsigne d Integer –1 N/A 0 or 1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
carr_lock_stat 65 Carrier lock status. 0 => Off 1 => Open (using only predicts) 2 => Acquiring, FFT Search 3 => Acquiring, Waiting for Lock Decision 4 => In Lock 5 => Out of Lock Unsigne d Integer –1 N/A 0 to 5 83
array_flag 66 Array flag. 0 => Non-arrayed 1 => Arrayed with FSP #1 2 => Arrayed with FSP #2 Unsigne d Integer –1 N/A 0 to 2 87
lna_num 67 LNA Number. Value of 0 indicates unknown. Unsigne d Integer –1 N/A 0 to 4 9
rcv_time_tag_delay 68 Receive time tag delay. Value used to offset downlink time tag (e.g., for Goldstone Beam Waveguide antennas). A value of -1.0 indicates invalid (or not provided). IEEE Double Seconds / 0.1 nsec -1.0, 0.0 to 1.0 3
dl_zheight_corr 76 Downlink Z-height correction. Value of -99.0 indicates invalid. IEEE Single Seconds / 0.1 nsec -99.0, -1.000 to 1.000 60, 72
vld_ul_stn 80 Validated uplink station. Per Reference [8]. The uplink station per the validation process. A value of 0 means that the antenna is unknown or not valid. Unsigne d Integer –1 N/A 0 to 255 61, 79
vld_dop_mode 81 Validated doppler mode. 0 => Unknown or not applicable 1 => One-way 2 => Two-way 3 => Three-way Unsigne d Integer –1 N/A 0 to 3 61, 79
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
vld_scft_coh 82 Validated spacecraft coherency. 0 => Unknown or not applicable 1 => Coherent 2 => Non-coherent 3 => Transponded, non-coherent Unsigne d Integer –1 N/A 0 to 3 79
vld_dl_band 83 Validated downlink frequency band. 0 => unknown 1 => S-band 2 => X-band 3 => Ka-band 4 => Ku-band 5 => L-band 6 => S or X band (26m stations) Unsigne d Integer –1 N/A 0 to 6 82
scft_transpd_lock 84 Spacecraft transponder lock. 0 => Unknown 1 => Out-of-lock 2 => In Lock Unsigne d Integer –1 N/A 0 to 2 5
scft_transpd_num 85 Spacecraft transponder number. 0 if unknown, transponder number otherwise. Unsigne d Integer –1 N/A 0 to 5 5
reserve2 86 Reserved. Unsigne N/A 0
Two bytes. d Integer
–2
scft_osc_freq 88 Spacecraft oscillator frequency. Spacecraft one-way frequency. 0.0 if unknown. IEEE Double Hz / 1.0 mHz 0.0, 2.0e9 to 32.3e9 6
scft_transpd_dela y 96 Spacecraft transponder delay. Coherent ranging delay. Value of -1.0 indicates invalid. IEEE Double Seconds / 0.1 nsec -1.0, 0.0 to 1.0 7
scft_transpd_turn _num 104 Spacecraft transponder turn around ratio numerator. A value of 0 indicates unknown. Unsigne d Integer –4 N/A 0 to 232-1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
scft_transpd_turn _den 108 Spacecraft transponder turn around ratio denominator. A value of 0 indicates unknown. Unsigne d Integer –4 N/A 0 to 232-1
scft_twnc_stat 112 Spacecraft two-way non-coherent (TWNC) status. 0 => Unknown 1 => OFF 2 => ON Unsigne d Integer1 N/A 0 to 2 5
scft_osc_type 113 Spacecraft oscillator type. 0 => Unknown 1 => AUX OSC (auxiliary oscillator) 2 => USO (ultra-stable oscillator) Unsigne d Integer –1 N/A 0 to 2 5
mod_day 114 Modification time days. Days since 1/1/1958. Last modification time. Unsigne d Integer –2 Days / 1 day 0 to 216 -1 73
mod_msec 116 Modification time milliseconds of day. Last modification time. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,99 9 73
cnt_time 120 Count time. Integration time of the counts. Value of 0 indicates Not Applicable IEEE Single Seconds / 0.1 sec 0.0 to 3600.0 88
version_num 124 Version number. Version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_version_num 125 Sub-version number. Sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_sub_version_ num 126 Sub-sub-version number. Sub-sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
lna_corr_value 127 LNA Correction Value. Indicates results of validation of LNA number. Value of 0 indicates no validation or correction was made, otherwise if non-zero, this value is to be used instead of lna_num . Unsigne d Integer –1 N/A 0 to 4 9
3.1.4.2 Secondary CHDO 132 (Uplink Data Types)

Secondary CHDO 132 is used for the following Uplink data types (format codes): Uplink Carrier Phase (data type 0), Uplink Sequential Ranging Phase (data type 2), Uplink PN Ranging Phase (data type 4), and Ramps (data type 9). Secondary CHDO 132 is defined in Table 3-5.

Table 3-5. Secondary CHDO 132 Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the secondary CHDO. Unsigned Integer –2 N/A 132
chdo_length 2 Length attribute of the secondary CHDO. Indicates the length, in bytes, of the value field (bytes after this item) of the secondary CHDO. Unsigne d Integer –2 bytes 66
orig_id 4 Originator ID. Indicates where this SFDU was originated. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
last_modifier_id 5 Last modifier ID. Indicates where the contents of this SFDU were last modified. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
reserve1 6 Reserved. For future expansion of scft_id. Unsigne d Integer –1 N/A 0
scft_id 7 Spacecraft number. Per Reference [3a]. Unsigne d Integer –1 N/A 1 to 255
upl_rec_seq_num 8 Uplink record sequence number (UPL RSN). This is the record sequence number reported by the uplink subsystem (UPL) equipment. Unsigne d Integer –4 N/A 0 to 232-1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rec_seq_num 12 Record sequence number (RSN). Begins with zero; increments by one for each successive uplink tracking SFDU of the same data type; wraps around from 232-1 to zero. Value is reset to zero when the data processing system software is restarted. Unsigne d Integer –4 N/A 0 to 232-1
year 16 Time tag year. Unsigne N/A 1958 to
d Integer 3000
–2
doy 18 Time tag day of year. Unsigned Integer –2 N/A 1 to 366
sec 20 Time tag seconds of day. IEEE Double Seconds / 0.01 sec 0.00 to 86,400.99 1
rct_day 28 Record creation time days. Days since 1/1/1958. Unsigne d Integer –2 Days / 1 day 0 to 216 - 1 74
rct_msec 30 Record creation time milliseconds of day. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,999 74
ul_dss_id 34 Uplink antenna number. Unsigne N/A 0 to 255
Per Reference [8]. d Integer
–1
ul_band 35 Uplink frequency band. 0 => unknown 1 => S-band Unsigne d Integer –1 N/A 0 to 5
2 => X-band
3 => Ka-band
4 => Ku-band
5 => L-band
ul_assembly_num 36 Uplink Assembly Number. Note that this is to allow for Unsigned Integer –1 N/A 0 to 2
potential future cases where there might be more than one uplink of the same band at the same antenna.
0 => Invalid/unknown 1 => S-/X-band uplink 2 => Ka-band uplink
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
transmit_num 37 Transmitter number. Value depends on transmitter used. A value of Unsigne d Integer –1 N/A 0 to 3
0 indicates unknown.
transmit_stat 38 Transmit status. 0 => not transmitting out the horn 1 => transmitting out the horn 2 => invalid/unknown Unsigne d Integer –1 N/A 0 to 2
transmit_mode 39 Transmitter mode. 0 => low power 1 => high power 2 => invalid/unknown Unsigned Integer –1 N/A 0 to 2
cmd_modul_stat 40 Command modulation status. 0 => OFF Unsigne d Integer –1 N/A 0 to 2
1 => ON
2 => invalid/unknown
rng_modul_stat 41 Ranging modulation status. 0 => OFF 1 => ON 2 => invalid/unknown Unsigne d Integer –1 N/A 0 to 2
fts_vld_flag 42 Frequency and Timing (FTS) validity. 0 => Equipment is not synced with FTS 1 => Equipment is synced with FTS Unsigne d Integer –1 N/A 0 or 1
reserve1a 43 Reserved. Unsigne N/A 0
One byte. d Integer
–1
transmit_time_tag _delay 44 Transmit time tag delay. Value used to offset uplink time tag (e.g., for Goldstone Beam Waveguide antennas). Value of -1.0 indicates invalid (or not provided). IEEE Double seconds / 0.1 nsec -1.0, 0.0 to 1.0 2
ul_zheight_corr 52 Uplink Z-height correction. Value of -99.0 indicates invalid. IEEE Single seconds / 0.1 nsec -99.0, 1.000 to 1.000 60
mod_day 56 Modification time days. Days since 1/1/1958. Last modification time. Unsigne d Integer –2 Days / 1 day 0 to 216 - 1 73
mod_msec 58 Modification time milliseconds of day. Last modification time. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,99 9 73
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
version_num 62 Version number. Version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_version_num 63 Sub-version number. Sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_sub_version_ num 64 Sub-sub-version number. Sub-sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
reserve1b 65 Reserved. Unsigne N/A 0
One byte. d Integer
–1
reserve4 66 Reserved. Unsigne N/A 0
Four bytes. d Integer
–4
3.1.4.3 Secondary CHDO 133 (Downlink Data Types)

Secondary CHDO 133 is used for the following Downlink data types (format codes): Downlink Carrier Phase (data type 1), Downlink Sequential Ranging Phase (data type 3), and Downlink PN Ranging Phase (data type 5). Secondary CHDO 133 is defined in Table 3-6.

Table 3-6. Secondary CHDO 133 Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the secondary CHDO. Unsigne d Integer –2 N/A 133
chdo_length 2 Length attribute of the secondary CHDO. Indicates the length, in bytes, of the value field (bytes after this item) of the secondary CHDO. Unsigne d Integer –2 bytes 110
orig_id 4 Originator ID. Indicates where this SFDU was originated. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
last_modifier_id 5 Last modifier ID. Indicates where the contents of this SFDU were last Unsigne d Integer –1 N/A 0 to 255
modified. Per Reference
[3b].
reserve1 6 Reserved. For future expansion of scft_id. Unsigne d Integer –1 N/A 0
scft_id 7 Spacecraft number. Per Reference [3a]. Unsigne d Integer –1 N/A 1 to 255
dtt_rec_seq_num 8 Downlink Record sequence number (DTT RSN). This is the record sequence number reported by the downlink subsystem (DTT) equipment. Unsigne d Integer –4 N/A 0 to 232-1
rec_seq_num 12 Record sequence number (RSN). Begins with zero; increments by one for each successive downlink tracking SFDU of the same data type; wraps around from 232-1 to zero. Value is reset to zero when the data processing system software is restarted. Unsigne d Integer –4 N/A 0 to 232-1
year 16 Time tag year. Unsigne N/A 1958 to
d Integer 3000
–2
doy 18 Time tag day of year. Unsigned Integer –2 N/A 1 to 366
sec 20 Time tag seconds of day. IEEE Double Seconds / 0.01 sec 0.00 to 86,400.9 1
9
rct_day 28 Record creation time days. Days since 1/1/1958. Unsigne d Integer –2 Days / 1 day 0 to 216 - 1 74
rct_msec 30 Record creation time milliseconds of day. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,999 74
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
dl_dss_id 34 Downlink antenna number. Per Reference [8]. Unsigne d Integer –1 N/A 0 to 255
dl_band 35 Downlink frequency band. 0 => Unknown 1 => S-band Unsigne d Integer –1 N/A 0 to 5
2 => X-band
3 => Ka-band
4 => Ku-band
5 => L-band
dl_chan_num 36 Downlink channel number. Unsigne N/A 1 to 24
d Integer
–1
prdx_mode 37 Predicts mode. Predicts subset used by downlink channel. 0 => No Predicts 1 => One-way 2 => Two-way 3 => Three-way Unsigne d Integer –1 N/A 0 to 3
ul_prdx_stn 38 Uplink station used for predicts. Valid only if prdx_mode is 2 or 3. Per Reference [8]. A value of 0 means that the number is unknown or not valid (e.g., no uplink). Unsigne d Integer –1 N/A 0 to 255
ul_band_dl 39 Uplink frequency band assumed by downlink. 0 => Unknown 1 => S-band 2 => X-band 3 => Ka-band 4 => Ku-band 5 => L-band Unsigned Integer –1 N/A 0 to 5
array_delay 40 Array delay value. Time delay added to path by arraying equipment. Obtained from arraying equipment. Any measurements include this delay. Valid only if Array Flag (array_flag) is non-zero. IEEE Double seconds / 0.1 nsec 0.0 to 1.0 4
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
fts_vld_flag 48 Frequency and Timing (FTS) validity. 0 => Equipment is not synced with FTS 1 => Equipment is synced with FTS Unsigne d Integer –1 N/A 0 or 1
carr_lock_stat 49 Carrier lock status. 0 => Off 1 => Open (only using predicts) 2 => Acquiring, FFT Search 3 => Acquiring, Waiting for Lock Decision 4 => In Lock 5 => Out of Lock Unsigne d Integer –1 N/A 0 to 5
array_flag 50 Array flag. 0 => Not arrayed 1 => Arrayed with FSP #1 2 => Arrayed with FSP #2 Unsigne d Integer –1 N/A 0 to 2 87
polarization 51 Polarization. 0 => RCP 1 => LCP Unsigne d Integer –1 N/A 0 or 1
diplxr_stat 52 Diplexer status. 0 => Low noise 1 => Diplexed Unsigne d Integer –1 N/A 0 or 1
lna_num 53 LNA Number. Value of 0 indicates unknown. Unsigned Integer –1 N/A 0 to 4 9
rf_if_chan_num 54 RF-to-IF Downconverter Channel number. Unsigned Integer –1 N/A 1 or 2
if_num 55 IF input number. Defines path into downlink channel. Unsigned Integer –1 N/A 1 to 3
rcv_time_tag_delay 56 Receive time tag delay. Value used to offset downlink time tag (e.g., for Goldstone Beam Waveguide antennas). A value of -1.0 indicates invalid (or not provided). IEEE Double seconds / 0.1 nsec -1.0, 0.0 to 1.0 3
dl_zheight_corr 64 Downlink Z-height correction. Value of -99.0 indicates invalid. IEEE Single seconds / 0.1 nsec -99.0, -1.000 to 1.000 60
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
vld_ul_stn 68 Validated uplink station. Per Reference [8]. The uplink station per the validation process. A value of 0 means that the antenna Unsigne d Integer –1 N/A 0 to 255 61, 79
is unknown or not valid.
vld_dop_mode 69 Validated doppler mode. 0 => Unknown or not applicable 1 => One-way 2 => Two-way 3 => Three-way Unsigne d Integer –1 N/A 0 to 3 61, 79
vld_scft_coh 70 Validated spacecraft coherency. 0 => Unknown or not applicable 1 => Coherent 2 => Non-coherent 3 => Transponded, non-coherent Unsigne d Integer –1 N/A 0 to 3 79
scft_transpd_lock 71 Spacecraft transponder lock. 0 => Unknown 1 => Out-of-lock 2 => In Lock Unsigne d Integer –1 N/A 0 to 2 5
scft_transpd_num 72 Spacecraft transponder number. 0 if unknown, transponder number otherwise. Unsigne d Integer –1 N/A 0 to 5 5
reserve1a 73 Reserved. Unsigne N/A 0
One byte. d Integer
–1
scft_osc_freq 74 Spacecraft oscillator frequency. Spacecraft one-way frequency. 0.0 if unknown. IEEE Double Hz / 1 mHz 0.0, 2.0e9 to 32.3e9 6
scft_transpd_delay 82 Spacecraft transponder delay. Coherent ranging delay. Value of -1.0 indicates invalid. IEEE Double Seconds / 0.1 nsec -1.0, 0.0 to 1.0 7
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
scft_transpd_turn _num 90 Spacecraft transponder turn around ratio numerator. A value of 0 indicates unknown. Unsigne d Integer –4 N/A 0 to 232-1
scft_transpd_turn _den 94 Spacecraft transponder turn around ratio denominator. A value of 0 indicates unknown. Unsigne d Integer –4 N/A 0 to 232-1
scft_twnc_stat 98 Spacecraft two-way non-coherent (TWNC) status. 0 => Unknown 1 => OFF 2 => ON Unsigne d Integer –1 N/A 0 to 2 5
scft_osc_type 99 Spacecraft oscillator type. 0 => Unknown 1 => AUX OSC (auxiliary oscillator) 2 => USO (ultra-stable oscillator) Unsigne d Integer –1 N/A 0 to 2 5
mod_day 100 Modification time days. Days since 1/1/1958. Last modification time. Unsigne d Integer –2 Days / 1 day 0 to 216 -1 73
mod_msec 102 Modification time milliseconds of day. Last modification time. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,9 99 73
version_num 106 Version number. Version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_version_num 107 Sub-version number. Sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_sub_version_ num 108 Sub-sub-version number. Sub-sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
lna_corr_value 109 LNA Correction Value. Indicates results of validation of LNA number. Value of 0 indicates no validation or correction was made, otherwise if non-zero, this value is to be used instead of lna_num. Unsigne d Integer –1 N/A 0 to 4 9
reserve4 110 Reserved. Four bytes. Unsigne d Integer –4 N/A 0
3.1.4.4 Secondary CHDO 135 (Interferometric Data Types)

Secondary CHDO 135 is used for the following Interferometric data type (format code): VLBI (data type 10). Secondary CHDO 135 is defined in Table 3-7.

Table 3-7. Secondary CHDO 135 Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the secondary CHDO. Unsigne d Integer –2 N/A 135
chdo_length 2 Length attribute of the secondary CHDO. Indicates the length, in bytes, of the value field (bytes after this item) of the secondary CHDO. Unsigne d Integer –2 bytes 88
orig_id 4 Originator ID. Indicates where this SFDU was originated. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
last_modifier_id 5 Last modifier ID. Indicates that the contents of this SFDU were last modified by the VLBI system. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
reserve1a 6 Reserved. For future expansion of scft_id. Unsigne d Integer –1 N/A 0
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
scft_id 7 Spacecraft number. Per Reference [3a] Unsigne d Integer –1 N/A 1 to 255
rec_seq_num 8 Record sequence number (RSN). Begins with zero; increments by one for each successive VLBI tracking SFDU of the same data type; wraps around from 232-1 to zero. Unsigne d Integer –4 N/A 0 to 232-1
year 12 Time tag year. Unsigne d Integer –2 N/A 1958 to 3000
doy 14 Time tag day of year. Unsigned Integer –2 N/A 1 to 366
sec 16 Time tag seconds of day. IEEE Double seconds / 0.1 msec 0.00 to 86,400.9 1
999
rct_day 24 Record creation time days. Days since 1/1/1958. Unsigne d Integer –2 Days / 1 day 0 to 216 - 1 74
rct_msec 26 Record creation time milliseconds of day. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,999 74
ul_dss_id 30 Primary uplink antenna number. Per Reference [8]. Unsigne d Integer –1 N/A 0 to 255
dl_dss_id 31 Primary downlink antenna number. Per Reference [8]. Unsigne d Integer –1 N/A 0 to 255
dl_dss_id_2 32 Secondary downlink antenna number. Per Reference [8]. Unsigne d Integer –1 N/A 0 to 255
dl_band 33 Downlink frequency band. 0 => unknown 1 => S-band 2 => X-band 3 => Ka-band 4 => Ku-band 5 => L-band Unsigne d Integer –1 N/A 0 to 5
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
prdx_mode 34 Predicts mode. 0 => No Predicts 1 => One-way 2 => Two-way 3 => Three-way Unsigne d Integer –1 N/A 0 to 3
ul_band 35 Uplink Frequency band. 0 => unknown 1 => S-band 2 => X-band 3 => Ka-band 4 => Ku-band 5 => L-band 6 => C-band Valid only if prdx_mode is 2 or 3. Per Reference [8]. A value of 0 means that the number is unknown or not valid (e.g., no uplink). Unsigne d Integer –1 N/A 0 to 6
rec_type 36 Record type. 71 => spacecraft DOD 72 => quasar DOD 73 => spacecraft DOR 74 => quasar DOR Unsigne d Integer –1 N/A 71 to 74
source_type 37 VLBI source. 0 => quasar 1 => spacecraft Unsigne d Integer –1 N/A 0 or 1
fts_vld_flag 38 Frequency and Timing (FTS) validity. 0 => Equipment is not synced with FTS 1 => Equipment is synced with FTS Unsigne d Integer1 N/A 0 or 1
reserve1b 39 Reserved. Unsigne d Integer1 N/A 0
array_flag 40 Array flag for primary antenna. 0 => Not arrayed 1 => Arrayed with FSP #1 2 => Arrayed with FSP #2 Unsigne d Integer –1 N/A 0 to 2 87
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
array_flag_2 41 Array flag for secondary antenna. 0 => Not arrayed 1 => Arrayed with FSP #1 2 => Arrayed with FSP #2 Unsigne d Integer –1 N/A 0 to 2 87
array_delay 42 Array delay value at primary antenna. Time delay added to signal path by arraying equipment. Obtained from arraying equipment. Any measurements include this delay. Valid only if Array Flag (array_flag) is nonzero. IEEE Double seconds / 0.1 nsec 0.0 to 1.0 4
array_delay_2 50 Array delay value at secondary antenna. Time delay added to path by arraying equipment. Obtained from arraying equipment. Any measurements include this delay. Valid only if Secondary Antenna Array Flag (array_flag_2) is nonzero. IEEE Double seconds / 0.1 nsec 0.0 to 1.0 4
rcv_time_tag_del ay 58 Receive time tag delay at primary antenna. Value offsets downlink time tag (e.g., for Goldstone Beam Wavefuide antennas). A value of –1.0 indicates invalid (or not provided). IEEE Double seconds / 0.1 nsec -1.0, 0.0 to 1.0
rcv_time_tag_del ay_2 66 Receive time tag delay at secondary antenna. Value offsets downlink time tag (e.g., for Goldstone Beam Wavefuide antennas). A value of – 1.0 indicates invalid (or not provided). IEEE Double seconds / 0.1 nsec -1.0, 0.0 to 1.0
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
mod_day 74 Modification time days. Days since 1/1/1958. Last modification time. Unsigne d Integer –2 Days / 1 day 0 to 216 -1 73
mod_msec 76 Modification time milliseconds of day. Last modification time. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,9 99 73
version_num 80 Version number. Version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_version_num 81 Sub-version number. Sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_sub_version_ num 82 Sub-sub-version number. Sub-sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
reserve1c 83 Reserved. Unsigne N/A 0
One byte. d Integer
–1
reserve8 84 Reserved. Unsigne N/A 0
Eight bytes. d Integer
–8
3.1.4.5 Secondary CHDO 136 (Filtered Data Types)

Secondary CHDO 136 is used for the following Filtered data types (format codes): Smoothed Noise (data type 12) and Allan Deviation (data type 13). These data types are only generated for DTT-type antennas. Secondary CHDO 136 is defined in Table 3-8.

Table 3-8. Secondary CHDO 136 Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the secondary CHDO. Unsigne d Integer –2 N/A 136
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the secondary CHDO. Indicates the length, in bytes, of the value field (bytes following this item) of the secondary CHDO. Unsigne d Integer –2 Bytes 98
orig_id 4 Originator ID. Indicates where this SFDU was originated. Per Reference [3b]. Unsigne d Integer –1 N/A 0 to 255
last_modifier_id 5 Last modifier ID. Indicates where the contents of this SFDU were last modified. Per Reference [3b] Unsigne d Integer –1 N/A 0 to 255
reserve1 6 Reserved. For future expansion of scft_id. Unsigne d Integer –1 N/A 0
scft_id 7 Spacecraft number. Unsigne N/A 1 to 255
Per Reference [3a]. d Integer
–1
rec_seq_num 8 Record sequence number (RSN). Begins with zero; increments by one for each successive filtered SFDU of the same data type; wraps around from 232-1 to zero. Value is reset to zero when the data processing system software is restarted. Unsigne d Integer –4 N/A 0 to 232-1
year 12 Time tag year. Unsigne N/A 1958 to
d Integer 3000
–2
doy 14 Time tag day of year. Unsigned Integer –2 N/A 1 to 366
sec 16 Time tag seconds of day. IEEE Double seconds / 0.01 sec 0.00 to 86,400.9 1
9
rct_day 24 Record creation time days. Days since 1/1/1958. Unsigne d Integer –2 Days / 1 day 0 to 216 - 1 74
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rct_msec 26 Record creation time milliseconds of day. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,999 74
dl_dss_id 30 Downlink antenna number. Unsigne N/A 0 to 255
Per Reference [8]. d Integer
–1
dl_band 31 Downlink frequency band. 0 => unknown 1 => S-band 2 => X-band 3 => Ka-band 4 => Ku-band 5 => L-band Unsigne d Integer –1 N/A 0 to 5
dl_chan_num 32 Downlink channel number. Unsigne N/A 1 to 24
d Integer
–1
prdx_mode 33 Predicts mode. 0 => No Predicts 1 => One-way 2 => Two-way 3 => Three-way Unsigne d Integer –1 N/A 0 to 3
ul_prdx_stn 34 Uplink station used for predicts. Valid only if prdx_mode is 2 or 3. Per Reference [8]. A value of 0 means that the number is unknown or not valid (e.g., no uplink). Unsigne d Integer –1 N/A 0 to 255
ul_band_dl 35 Uplink band assumed by downlink. 0 => Unknown or not applicable 1 => S-band 2 => X-band 3 => Ka-band 4 => Ku-band 5 => L-band Unsigned Integer –1 N/A 0 to 5
rcv_time_tag_ delay 36 Receive time tag delay. Value used to offset IEEE Double seconds / 0.1 nsec -1.0, 0.0 to 1.0 3
downlink time tag (e.g., for Goldstone Beam Waveguide antennas). A value of -1.0 indicates invalid (or not provided).
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
array_delay 44 Array delay value. Time delay added to path by arraying equipment. Obtained from arraying equipment. Any measurements include this delay. Valid only if Array Flag (array_flag) is non-zero. IEEE Double seconds / 0.1 nsec 0.0 to 1.0 4
fts_vld_flag 52 Frequency and Timing (FTS) validity. 0 => Equipment is not synced with FTS 1 => Equipment is synced with FTS Unsigned Integer –1 N/A 0 or 1
carr_lock_stat 53 Carrier lock status. 0 => Off Unsigned Integer –1 N/A 0 to 5
1 => Open (only using predicts) 2 => Acquiring, FFT Search 3 => Acquiring, Waiting for Lock Decision
4 => In Lock
5 => Out of Lock
array_flag 54 Array flag. 0 => Not arrayed 1 => Arrayed with FSP #1 2 => Arrayed with FSP #2 Unsigne d Integer –1 N/A 0 to 2 87
lna_num 55 LNA Number. Value of 0 indicates unknown. Unsigned Integer –1 N/A 0 to 4
vld_ul_stn 56 Validated uplink station. Per Reference [8]. The uplink station per the validation process. A value of 0 means that the antenna is unknown or not valid. Unsigne d Integer –1 N/A 0 to 255 61, 79
vld_dop_mode 57 Validated doppler mode. 0 => Unknown or not applicable 1 => One-way 2 => Two-way 3 => Three-way Unsigne d Integer –1 N/A 0 to 3 61, 79
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
vld_scft_coh 58 Validated spacecraft coherency. 0 => Unknown or not applicable 1 => Coherent 2 => Non-coherent 3 => Transponded, non-coherent Unsigne d Integer –1 N/A 0 to 3 79
scft_transpd_lock 59 Spacecraft transponder lock. 0 => Unknown 1 => Out-of-lock 2 => Locked Unsigne d Integer –1 N/A 0 to 2 5
scft_transpd_num 60 Spacecraft transponder number. 0 if unknown, transponder number otherwise. Unsigne d Integer –1 N/A 0 to 5 5
reserve1a 61 Reserved. Unsigne N/A 0
One byte. d Integer
–1
scft_osc_freq 62 Spacecraft oscillator frequency. Spacecraft one-way frequency. 0.0 if unknown. IEEE Double Hz / 1 mHz 0.0, 2.0e9 to 32.3e9 6
scft_transpd_delay 70 Spacecraft transponder delay. Coherent ranging delay. Value of -1.0 indicates invalid. IEEE Double Seconds / 0.1 nsec -1.0, 0.0 to 1.0 7
scft_transpd_turn _num 78 Spacecraft transponder turn around ratio numerator. Unsigne d Integer N/A 0 to 232-1
A value of 0 indicates –4
unknown.
scft_transpd_turn _den 82 Spacecraft transponder turn around ratio denominator. A value of 0 indicates unknown. Unsigne d Integer –4 N/A 0 to 232-1
scft_twnc_stat 86 Spacecraft two-way non-coherent (TWNC) status. 0 => Unknown 1 => OFF 2 => ON Unsigne d Integer –1 N/A 0 to 2 5
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
scft_osc_type 87 Spacecraft oscillator type. 0 => Unknown 1 => AUX OSC (auxiliary oscillator) 2 => USO (ultra-stable oscillator) Unsigne d Integer –1 N/A 0 to 2 5
mod_day 88 Modification time days. Days since 1/1/1958. Last modification time. Unsigne d Integer –2 Days / 1 day 0 to 216 -1 73
mod_msec 90 Modification time milliseconds of day. Last modification time. Unsigne d Integer –4 msec / 1 msec 0 to 86,400,9 99 73
version_num 94 Version number. Version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_version_num 95 Sub-version number. Sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
sub_sub_version_ num 96 Sub-sub-version number. Sub-sub-version number of the assembly that generated the data. Unsigne d Integer –1 N/A 0 to 63
reserve1b 97 Reserved. Unsigne N/A 0
One byte. d Integer
–1
reserve4 98 Reserved. Unsigne N/A 0
Four bytes. d Integer
–4

3.1.5 Tracking Data CHDOs

There are 18 types of Tracking Data CHDOs, split into five categories: uplink data, downlink data, derived data, interferometric data, and filtered data. Uplink data are the validated uplink phases from the UPL-DTT antennas and the uplink ramps. Downlink data are the validated downlink phases from the UPL-DTT antennas. Derived data are the data from the non-UPL-DTT antennas, and the processed doppler, range and DRVID data from the UPL-DTT antennas. Interferometric data are the VLBI data. Filtered data are the measurements derived from the accumulated downlink carrier phase data (smoothed noise and Allan Deviation) and are only available for UPL-DTT antennas. The data types are as follows:

    • Uplink Data

      • Uplink Carrier Phase (data type 0)

      • Uplink Sequential Ranging Phase (data type 2)

      • Uplink PN Ranging Phase (data type 4)

      • Ramp (data type 9)

    • Downlink Data

      • Downlink Carrier Phase (data type 1)

      • Downlink Sequential Ranging Phase (data type 3)

      • Downlink PN Ranging Phase (data type 5)

    • Derived Data

      • Doppler Count (data type 6)

      • Sequential Range (data type 7)

      • Angle (data type 8)

      • DRVID (data type 11)

      • PN Range (data type 14)

      • Tone Range (data type 15)

      • Carrier Frequency Observable (data type 16)

      • Total Count Phase Observable (data type 17)

    • Interferometric Data

    • • VLBI (data type 10)
    • Filtered Data

      • Smoothed Noise (data type 12)

      • Allan Deviation (data type 13)

3.1.5.1 Uplink Data CHDOs

There are four Uplink Data CHDOs: Uplink Carrier Phase (data type 0), Uplink Sequential Ranging Phase (data type 2), Uplink PN Ranging Phase (data type 4), and Ramp (data type 9). Their formats and contents are specified in sections 3.1.5.1.1 to 3.1.5.1.4.

3.1.5.1.1 Uplink Carrier Phase CHDO (Data Type 0)

The Uplink Carrier Phase CHDO is defined in Table 3-9.

Table 3-9. Uplink Carrier Phase CHDO (Data Type 0) Definitions

Identifier Byte Offsets Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the uplink carrier phase data CHDO. CHDO contains binary data. Unsigned Integer – 2 N/A 10
Identifier Byte Offsets Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the uplink carrier phase data CHDO value field. Number of bytes after this item. Unsigned Integer – 2 bytes 76
ul_hi_phs_cycles 4 High part phase data whole cycles. Unsigned Integer – 4 Total integer phase cycles divided by 232 0 to 232-1 8
ul_lo_phs_cycles 8 Low part phase data whole cycles. Unsigned Integer – 4 Total integer phase cycles modulo 232 0 to 232-1 8
ul_frac_phs_cycle s 12 Fractional part phase data cycles. Unsigned Integer – 4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
ramp_freq 16 Ramp frequency. Precision varies with band (phase data gives higher precision). A value of 0.0 indicates an invalid or unknown value S-band => 0.5 μHz X-band => 1.6 μHz Ka-band => 7.7 μHz IEEE Double Sky level Hz, at least 7.7 μHz precision (band dependen t) 0.0, 2.0e9 to 34.7e9
ramp_rate 24 Ramp rate. IEEE Double Sky level Hz/sec, μHz/sec precision -3.2e5 to 3.2e5
transmit_switch_s tat 32 Transmitter switch status. 0 => antenna 1 => water load 2 => invalid/unknown Unsigned Integer – 1 N/A 0 to 2
Identifier Byte Offsets Item Name and Description Format Units/ Precision Range Notes
ramp_type 33 Ramp type. 0 => snap 1 => start of new ramp 2 => medial report 3 => periodic report 4 => end of ramps 5 => ramping terminated by operator 6 => invalid/unknown Unsigned Integer –1 N/A 0 to 6
transmit_op_pwr 34 Transmitter output power. IEEE Single W / 0.1 W 0.0 to 500,000.0
sup_data_id 38 Support data ID. Name of the frequency predicts set used. ASCII –8 N/A ASCII string
sup_data_rev 46 Support data revision. Revision of the frequency predicts set used. ASCII –8 N/A ASCII string
prdx_time_offset 54 Predicts time offset. Seconds added to current time. IEEE Double Seconds / 0.1 sec -31,536, 000.0 to 31,536,0 00.0 54
prdx_freq_offset 62 Predicts frequency offset. IEEE Hz / 1 -4.8e6 to 55
Hz added to predicted value. Double mHz 4.8e6
time_tag_corr_fla g 70 Time tag correction flag. Indicates results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigned Integer – 1 N/A 0 to 2
type_time_corr_fl ag 71 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigned Integer – 1 N/A 0 to 3
Identifier Byte Offsets Item Name and Description Format Units/ Precision Range Notes
reserve8 72 Reserved. Eight bytes. Unsigned Integer – 8 N/A 0
3.1.5.1.2 Uplink Sequential Ranging Phase CHDO (Data Type 2)

The Uplink Sequential Ranging Phase CHDO is defined in Table 3-10.

Table 3-10. Uplink Sequential Ranging Phase CHDO (Data Type 2) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the uplink sequential ranging phase data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the uplink sequential ranging phase data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 108
stn_cal 4 Station calibration value. (Two-way). Value includes the equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 24
ul_stn_cal 12 Uplink station calibration value. Value includes the uplink equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 10,24
ul_cal_freq 20 Uplink calibration frequency. Frequency the calibration was done at. IEEE Double Sky level Hz / 1 mHz 2.0e9 to 34.4e9
cal_std_dev 28 Standard deviation of station IEEE Range 0.0 to 24
calibration value. Single Units / 1.8e5
For stn_cal and ul_stn_cal. 0.01 RU
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
cal_pts 32 Calibration points. Number of measurements Unsigned Integer –2 N/A 0 to 65,535
made in computing station calibration values (stn_cal, ul_stn_cal, cal_std_dev).
ul_rng_phs 34 Measured range phase. Range phase. IEEE Double Range Units / 0.01 RU 0.0 to 230 11,24
transmit_switch_s tat 42 Transmitter switch status. 0 => antenna 1 => water load 2 => invalid/unknown Unsigne d Integer –1 N/A 0 to 2
invert 43 Invert. Polarity of modulation. 0 => not inverted 1 => inverted Unsigne d Integer –1 N/A 0 or 1 52
transmit_op_pwr 44 Transmitter output power. IEEE Single W / 0.1 W 0.0 to 500,000.0
template_id 48 Template ID. Value is the file name of the ranging parameter file. ASCII – 8 N/A ASCII string
t1 56 T1 setting. Unsigne d Integer –2 Seconds / 1 sec 1 to 3600 12
t2 58 T2 setting. Unsigne Seconds / 1 to 13
d Integer 1 sec 1800
–2
t3 60 T3 setting. Unsigne d Integer –2 Seconds / 1 sec 0 to 1800 14
first_comp_num 62 First component number. Unsigne d Integer –1 N/A 1 to 24 15
last_comp_num 63 Last component number. Unsigne d Integer –1 N/A 1 to 24 15
chop_comp_num 64 Chop component number. This is the component used to chop the other components. Unsigne d Integer –1 N/A 0 to 10 15,16
num_drvid 65 Number of DRVID Unsigne N/A 0 to 255
measurements. d Integer
–1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
transmit_inphs_ti me_year 66 Transmit In-phase time – year. Year of the time of zero phase on uplink range generation. Unsigne d Integer –2 N/A 1958 to 3000 75
transmit_inphs_ti me_doy 68 Transmit In-phase time – day of year. Day of year of the time of zero phase on uplink range generation. Unsigne d Integer –2 N/A 1 to 366 75
transmit_inphs_ti me_sec 70 Transmit In-phase time – seconds of day. Seconds of day of the time of zero phase on uplink range generation. IEEE Double Seconds / 1 μsec 0.00000 0 to 86,400.9 99999 75
carr_sup_rng_mo dul 78 Carrier Suppression by ranging modulation. Reduction in carrier power due to ranging modulation. IEEE Single dB / 0.1 dB 0.0 to 15.0
rng_modul_amp 82 Ranging modulation amplitude. Actual digital modulation amplitude used by the ranging hardware. Unsigne d Integer –2 N/A 0 to 212
exc_scalar_num 84 Exciter Scalar Numerator. Numerator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
exc_scalar_den 88 Exciter Scalar Denominator. Denominator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
rng_cycle_time 92 Ranging cycle time. Time to complete one cycle of the ranging code. IEEE Double Seconds / 0.1 sec 4.0 to 504,536. 0 18
time_tag_corr_fla g 100 Time tag correction flag. Indicates results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
type_time_corr_fl ag 101 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigne d Integer –1 N/A 0 to 3
clock_waveform 102 Clock waveform type. Unsigne N/A 0 or 1
0 => squarewave d Integer
1 => sinewave -1
chop_start_num 103 Chop Start. Unsigne N/A 0 to 25 16
The first component chopped. d Integer
–1
rng_meas_type 104 Range Measurement Type. Type of sequential measurement. 0 => ranging measurement 1 => calibration Unsigne d Integer –1 N/A 0 or 1
reserve1 105 Reserved. Unsigne N/A 0
One byte. d Integer
–1
reserve6 106 Reserved. Unsigne N/A 0
Six bytes. d Integer
–6
3.1.5.1.3 Uplink PN Ranging Phase CHDO (Data Type 4)

The Uplink PN Ranging Phase CHDO is defined in Table 3-11.

Table 3-11. Uplink PN Ranging Phase CHDO (Data Type 4) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the uplink PN ranging phase data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the uplink PN ranging phase data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 190
stn_cal 4 Station calibration value. (two-way). Value includes the equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 24
ul_stn_cal 12 Uplink station calibration value. Value includes the uplink equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 10,24
ul_cal_freq 20 Uplink calibration frequency. Frequency the calibration was done at. IEEE Double Sky level Hz / 1 mHz 2.0e9 to 34.4e9
cal_std_dev 28 Standard deviation of station calibration value. For stn_cal and ul_stn_cal. IEEE Single Range Units / 0.01 RU 0.0 to 1.8e5 24
cal_pts 32 Calibration points. Number of measurements made in computing station calibration values (stn_cal, ul_stn_cal, and cal_std_dev). Unsigne d Integer –2 N/A 0 to 65,535
ul_rng_phs 34 Measured range phase. Range phase. IEEE Double Range Units / 0.01 RU 0.0 to 230 11,24
state_subcode1 42 Subcode #1 code state. Position in the subcode at the time tag. Unsigne d Integer –1 N/A 0 to 63 19
state_subcode2 43 Subcode #2 code state. Position in the subcode at the time tag. Unsigne d Integer –1 N/A 0 to 63 19
state_subcode3 44 Subcode #3 code state. Position in the subcode at the time tag. Unsigne d Integer –1 N/A 0 to 63 19
state_subcode4 45 Subcode #4 code state. Position in the subcode at the time tag. Unsigne d Integer –1 N/A 0 to 63 19
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
state_subcode5 46 Subcode #5 code state. Unsigne N/A 0 to 63 19
Position in the subcode at the d Integer
time tag. –1
state_subcode6 47 Subcode #6 code state. Position in the subcode at the time tag. Unsigne d Integer –1 N/A 0 to 63 19
pn_clk_phs 48 PN chip clock phase. Position in the chip at the time tag. IEEE Double Cycles / 1 μcycle 0.0 to 1.0 19
transmit_switch_s tat 56 Transmitter switch status. 0 => antenna 1 => water load 2 => invalid/unknown Unsigne d Integer –1 N/A 0 to 2
invert 57 Invert. Polarity of modulation signal. 0 => not inverted 1 => inverted Unsigne d Integer –1 N/A 0 or 1 52
transmit_op_pwr 58 Transmitter output power. IEEE W / 0.1 0.0 to
Single W 500,000.
0
template_id 62 Template ID. Ranging configuration file ID, or the name of the PN pattern if configured by operator directive. ASCII – 22 N/A ASCII string
clk_divider 84 Clock divider. Value that exciter ranging reference frequency is divided by to get PN chip rate. Unsigne d Integer –1 N/A 1 to 64 20
len_subcode1 85 SequenceSubcode #1 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
len_subcode2 86 Subcode #2 length. Unsigne Chips / 0 to 64 21
A value of 0 implies no d Integer 1 chip
subcode. –1
len_subcode3 87 Subcode #3 length. Unsigne Chips / 0 to 64 21
A value of 0 implies no d Integer 1 chip
subcode. –1
len_subcode4 88 Subcode #4 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
len_subcode5 89 Subcode #5 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
len_subcode6 90 Subcode #6 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
op_subcode1 91 Operation #1. Logical operation between the accumulated pattern and the next subcode. 0 => AND 1 => OR 2 => XOR 3 => Majority Vote Unsigne d Integer –1 N/A 0 to 3
op_subcode2 92 Operation #2. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
op_subcode3 93 Operation #3. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
op_subcode4 94 Operation #4. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
op_subcode5 95 Operation #5. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
def_subcode1 96 Subcode #1 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode2 104 Subcode #2 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode3 112 Subcode #3 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode4 120 Subcode #4 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode5 128 Subcode #5 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
def_subcode6 136 Subcode #6 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
pn_code_length 144 Code Length. Unsigne d Integer –4 PN chips / 1 chip 2 to 1100000 0 22
transmit_inphs_ti me_year 148 Transmit In-phase time – year. Year of the time of zero phase on uplink range generation. Unsigne d Integer –2 N/A 1958 to 3000 75
transmit_inphs_ti me_doy 150 Transmit In-phase time – day of year. Day of year of the time of zero phase on uplink range generation. Unsigne d Integer –2 N/A 1 to 366 75
transmit_inphs_ti me_sec 152 Transmit In-phase time – seconds of day. Seconds of day of the time of zero phase on uplink range generation. IEEE Double Seconds / 1 μsec 0.00000 0 to 86,400.9 99999 75
carr_sup_rng_mo dul 160 Carrier Suppression by ranging modulation. Reduction in carrier power due to ranging modulation. IEEE Single dB / 0.1 dB 0.0 to 15.0
rng_modul_amp 164 Ranging modulation amplitude. Actual digital modulation amplitude used by the ranging hardware. Unsigne d Integer –2 N/A 0 to 212
exc_scalar_num 166 Exciter Scalar Numerator. Numerator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
exc_scalar_den 170 Exciter Scalar Denominator. Denominator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
rng_cycle_time 174 Ranging cycle time. Time to complete one cycle of ranging code. IEEE Double Range Units / 0.01 RU 0.0 to 1.0e9 23,24
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
clock_waveform 182 Clock waveform type. Unsigne N/A 0 or 1
0 => squarewave d Integer
1 => sinewave -1
rng_meas_type 183 Range Measurement Type. Type of PN measurement. 0 => spacecraft Unsigne d Integer –1 N/A 0 or 1
measurement
1 => calibration
time_tag_corr_fla g 184 Time tag correction flag. Indicates results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
type_time_corr_fl ag 185 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigne d Integer –1 N/A 0 to 3
reserve8 186 Reserved. Unsiged N/A 0
Eight bytes. Integer
8
3.1.5.1.4 Ramp CHDO (Data Type 9)

For UPL-DTT antennas the Ramp CHDO is generated only when ramp_type equals 0, 1, 4, or 5, OR when transmit_stat changes. For non-UPL-DTT antennas the Ramp CHDO is generated at the beginning of a pass or when either prdx_mode or ul_band_dl changes for a given spacecraft. The Ramp CHDO is defined in Table 3-12.

Table 3-12. Ramp CHDO (Data Type 9) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the ramp data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the ramp data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 38
ul_hi_phs_cycles 4 High part uplink phase data whole cycles. Phase at time tag. Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
ul_lo_phs_cycles 8 Low part uplink phase data whole cycles. Phase at time tag. Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
ul_frac_phs_cycles 12 Fractional part uplink phase data cycles. Phase at time tag. Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
ramp_freq 16 Ramp frequency. Precision varies with band (phase data gives higher precision). A value of 0.0 indicates an invalid or unknown value. S-band => 0.5 μHz X-band => 1.6 μHz Ka-band => 7.7 μHz IEEE Double Sky level Hz, at least 7.7 μHz precision (band dependen t) 0.0, 2.0e9 to 34.7e9
ramp_rate 24 Ramp rate. IEEE Double Sky level Hz/sec, μHz/sec precision -3.2e5 to 3.2e5
ramp_type 32 Ramp type. 0 => snap 1 => start of new ramp 2 => medial report 3 => periodic report 4=> end of ramps 5 => ramping terminated by Unsigned Integer –1 N/A 0 to 6
operator 6 => invalid/unknown
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
reserve1 33 Reserved. One byte. Unsigne d Integer –1 N/A 0
reserve8 34 Reserved. Eight bytes. Unsigne d Integer –8 N/A 0
3.1.5.2 Downlink Data CHDOs

There are three Downlink Data CHDOs: Downlink Carrier Phase (data type 1), Downlink Sequential Ranging Phase (data type 3), and Downlink PN Ranging Phase (data type 5). Their formats and contents are specified in sections 3.1.5.2.1 to 3.1.5.2.3.

3.1.5.2.1 Downlink Carrier Phase CHDO (Data Type 1)

The Downlink Carrier Phase CHDO is defined in Table 3-13.

Table 3-13. Downlink Carrier Phase CHDO (Data Type 1) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the downlink carrier phase data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the downlink carrier phase data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 228
carr_loop_bw 4 Carrier tracking loop bandwidth. IEEE Single Hz / 1 mHz 0.1 to 50.0
pcn0 8 Pc/N0. Carrier power to noise spectral density ratio. Has a value of –300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz 0.0 to 90.0, -300.0
pcn0_resid 12 Pc/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
pdn0 16 Pd/N0. Data power to noise spectral density ratio. Has a value of –300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz 0.0 to 90.0, -300.0 25
pdn0_resid 20 Pd/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
system_noise _temp 24 System Noise Temperature. IEEE Single k (degrees kelvin) / 0.1 k 0.1 to 2000.0
phs_hi_0 28 Raw phase sample 0 – High part phase data whole cycles. (time tag + 0.0 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_0 32 Raw phase sample 0 – Low part phase data whole cycles. (time tag + 0.0 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_0 36 Raw phase sample 0 – Fractional part phase data cycles. (time tag + 0.0 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_1 40 Raw phase sample 1 – High part phase data whole cycles. (time tag + 0.1 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_1 44 Raw phase sample 1 – Low part phase data whole cycles. (time tag + 0.1 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
phs_frac_1 48 Raw phase sample 1 – Fractional part phase data cycles. (time tag + 0.1 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_2 52 Raw phase sample 2 – High part phase data whole cycles. (time tag + 0.2 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_2 56 Raw phase sample 2 – Low part phase data whole cycles. (time tag + 0.2 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_2 60 Raw phase sample 2 – Fractional part phase data cycles. (time tag + 0.2 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_3 64 Raw phase sample 3 – High part phase data whole cycles. (time tag + 0.3 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_3 68 Raw phase sample 3 – Low part phase data whole cycles. (time tag + 0.3 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_3 72 Raw phase sample 3 – Fractional part phase data cycles. (time tag + 0.3 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
phs_hi_4 76 Raw phase sample 4 – High part phase data whole cycles. (time tag + 0.4 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_4 80 Raw phase sample 4 – Low part phase data whole cycles. (time tag + 0.4 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_4 84 Raw phase sample 4 – Fractional part phase data cycles. (time tag + 0.4 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_5 88 Raw phase sample 5 – High part phase data whole cycles. (time tag + 0.5 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_5 92 Raw phase sample 5 – Low part phase data whole cycles. (time tag + 0.5 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_5 96 Raw phase sample 5 – Fractional part phase data cycles. (time tag + 0.5 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_6 100 Raw phase sample 6 – High part phase data whole cycles. (time tag + 0.6 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
phs_lo_6 104 Raw phase sample 6 – Low part phase data whole cycles. (time tag + 0.6 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_6 108 Raw phase sample 6 – Fractional part phase data cycles. (time tag + 0.6 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_7 112 Raw phase sample 7 – High part phase data whole cycles. (time tag + 0.7 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_7 116 Raw phase sample 7 – Low part phase data whole cycles. (time tag + 0.7 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_7 120 Raw phase sample 7 – Fractional part phase data cycles (time tag + 0.7 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_8 124 Raw phase sample 8 – High part phase data whole cycles. (time tag + 0.8 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_8 128 Raw phase sample 8 – Low part phase data whole cycles. (time tag + 0.8 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
phs_frac_8 132 Raw phase sample 8 – Fractional part phase data cycles. (time tag + 0.8 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_9 136 Raw phase sample 9 – High part phase data whole cycles. (time tag + 0.9 sec) Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_9 140 Raw phase sample 9 – Low part phase data whole cycles. (time tag + 0.9 sec) Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_9 144 Raw phase sample 9 – Fractional part phase data cycles. (time tag + 0.9 sec) Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
phs_hi_avg 148 Averaged phase sample – High part phase data whole cycles. One-second average, centered around time tag. Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8
phs_lo_avg 152 Averaged phase sample – Low part phase data whole cycles. One-second average, centered around time tag. Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8
phs_frac_avg 156 Averaged phase sample – Fractional part phase data cycles. One-second average, centered around time tag. Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8
dl_freq 160 Downlink frequency. Frequency at the time tag. IEEE Double Sky level Hz / 1 mHz 2.2e9 to 32.3e9
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
dop_resid 168 Doppler residual. Negative of frequency residual. IEEE Single Sky level Hz / 1 mHz -1.0e6 to 1.0e6
dop_noise 172 Doppler noise. Averaged over 10 points in record. IEEE Single Hz / 1 mHz 0.0 to 1000.0 26
slipped_cycles 176 Slipped cycles. Integer – 4 N/A -10 to 10 31
carr_loop_type 180 Carrier loop type. Unsigned Integer –1 N/A 1 to 3 53
snt_flag 181 SNT measurement flag. 0 => SNT value is the predicted value 1 => SNT value is the measured value Unsigned Integer –1 N/A 0 or 1
carr_resid_wt 182 Carrier residual weight. (Weight value applied to residual phase error in carrier tracking; suppressed carrier weight is 1.0 minus this value.) IEEE Single N/A 0.0 to 1.0 27
sup_data_id 186 Support data ID. Name of the frequency predicts set used. ASCII – 8 N/A ASCII String
sup_data_rev 194 Support data revision. Revision of the frequency predicts set used. ASCII – 8 N/A ASCII String
prdx_time_offset 202 Predicts time offset. Seconds added to current time. IEEE Double Seconds / 1 msec -8.64e4 to 8.64e4 54
prdx_freq_offset 210 Predicts frequency offset. Hz added to predicted value. IEEE Double Hz / 1 mHz -1.0e6 to 1.0e6 55
carr_resid_tol_flag 218 Carrier residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigne d Integer –1 N/A 0 or 1 62
time_tag_corr_flag 219 Time tag correction flag. Indicates results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
type_time_corr_fla g 220 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigne d Integer –1 N/A 0 to 3
dop_mode_corr_fl ag 221 Doppler mode correction flag. Indicates the results of the validation of the doppler mode. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
ul_stn_corr_flag 222 Uplink station correction flag. Indicates the results of the validation of the uplink station. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
reserve1 223 Reserved. One byte. Unsigne d Integer –1 N/A 0
reserve8 224 Reserved. Unsigne N/A 0
Eight bytes. d Integer
–8
3.1.5.2.2 Downlink Sequential Ranging Phase CHDO (Data Type 3)

The Downlink Sequential Ranging Phase CHDO is defined in Table 3-14.

Table 3-14. Downlink Sequential Ranging Phase CHDO (Data Type 3) Definitions


Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the downlink sequential ranging phase data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the downlink sequential ranging phase data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 174
stn_cal 4 Station calibration value. (Two-way). Value includes the equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 24
dl_stn_cal 12 Downlink station calibration value. Value includes the downlink equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 10,24
dl_cal_freq 20 Downlink calibration frequency. Frequency the calibration was done at. IEEE Double Sky level Hz / 1 mHz 2.2e9 to 32.3e9
cal_std_dev 28 Standard deviation of station calibration value. For stn_cal and dl_stn_cal. IEEE Single Range Units / 0.01 RU 0.0 to 1.8e5 24
cal_pts 32 Calibration points. Number of measurements made in computing station calibration values (stn_cal, dl_stn_cal, and cal_std_dev). Unsigne d Integer –2 N/A 0 to 65,535
dl_rng_phs 34 Measured range phase. Range phase. IEEE Double Range Units / 0.01 RU 0.0 to 230 11,24
figure_merit 42 Figure of Merit. Rating of the measured range value. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 28
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rng_resid 46 Range residual. Measured range minus predicted range. IEEE Double Range Units / 0.01 RU -230 to 230 29
drvid 54 DRVID. DRVID measured using phase data from carrier. IEEE Double Range Units / 0.01 RU -230 to 230 30, 81
rtlt 62 Round trip light time. Predicted value. IEEE Single Seconds / 0.1 sec 0.0 to 86,400.0
pcn0 66 Pc/N0. Carrier power to noise spectral density ratio. Has a value of –300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz 0.0 to 90.0, -300.0
pcn0_resid 70 Pc/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
pdn0 74 Pd/N0. Data power to noise spectral density ratio. Has a value of –300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz 0.0 to 90.0, -300.0 25
pdn0_resid 78 Pd/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
prn0 82 Pr/N0. Ranging power to noise spectral density ratio. Has a value of –300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0, -300.0
prn0_resid 86 Pr/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
system_noise_temp 90 System Noise Temperature. IEEE Single K (degrees Kelvin) / 0.1 K 0.1 to 2000.0
carr_loop_type 94 Carrier loop type. Unsigne N/A 1 to 3 53
d Integer
–1
snt_flag 95 SNT measurement flag. 0 => SNT value is the predicted value 1 => SNT value is the measured value Unsigned Integer –1 N/A 0 or 1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
carr_resid_wt 96 Carrier residual weight. (Weight value applied to residual phase error in carrier tracking; suppressed carrier weight is 1.0 minus this value.) IEEE Single N/A 0.0 to 1.0 27
template_id 100 Template ID. Value is the file name of the ranging parameter file. ASCII – 8 N/A ASCII string
invert 108 Invert. Inverted implies that the polarity of the correlation reference is the invert of what was transmitted. 0 => not inverted 1 => inverted Unsigne d Integer –1 N/A 0 or 1 52
correl_type 109 Correlation type. 0 => squarewave 1 => sinewave Unsigne d Integer –1 N/A 0 or 1
t1 110 T1 setting. Unsigne Seconds / 1 to 3600 12
d Integer 1 sec
–2
t2 112 T2 setting. Unsigne Seconds / 1 to 1800 13
d Integer 1 sec
–2
t3 114 T3 setting. Unsigne d Integer –2 Seconds / 1 sec 0 to 1800 14
first_comp_num 116 First component number. Unsigne d Integer –1 N/A 1 to 24 15
last_comp_num 117 Last component number. Unsigne d Integer –1 N/A 1 to 24 15
chop_comp_num 118 Chop component number. This is the component used to chop the other components. Unsigne d Integer –1 N/A 0 to 10 15, 16
num_drvid 119 Number of DRVID Unsigne N/A 0 to 255
measurements. d Integer
–1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rcv_inphs_time_year 120 Receive In-phase time – year. Year of the time of zero phase on downlink range signal correlation. Unsigne d Integer –2 N/A 1958 to 3000 75
rcv_inphs_time_doy 122 Receive In-phase time – day of year. Day of year of the time of zero phase on downlink range signal correlation. Unsigne d Integer –2 N/A 1 to 366 75
rcv_inphs_time_sec 124 Receive In-phase time – seconds of day. Seconds of day of the time of zero phase on downlink range signal correlation. IEEE Double Seconds / 1 μsec 0.000000 to 86,400.9 99999 75
exc_scalar_num 132 Exciter Scalar Numerator. Numerator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
exc_scalar_den 136 Exciter Scalar Denominator. Denominator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
rng_cycle_time 140 Ranging cycle time. Time to complete one cycle of the ranging code. IEEE Double Seconds / 0.1 sec 4.0 to 504,536.0 18
inphs_correl 148 In phase correlation value. The in phase value of the clock component correlation. IEEE Single N/A -1.000e8 to 1.000e8
quad_phs_correl 152 Quadrature phase correlation value. The quadrature phase value of the clock component correlation. IEEE Single N/A -1.000e8 to 1.000e8
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
metrics_vld_flag 156 Metrics validity flag. Validity of the Range Residual (rng_resid) and DRVID (drvid) measurements. 0 => Invalid (No uplink data available) 1 => Invalid (Other reasons) 2 => Valid Unsigned Integer –1 N/A 0 to 2 70
correl_vld_flag 157 Correlation validity flag. 0 => Invalid 1 => Valid Unsigned Integer –1 N/A 0 or 1 56
rng_resid_tol_flag 158 Range residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 63
drvid_tol_flag 159 DRVID tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 64
prn0_resid_tol_fla g 160 Pr/N0 residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 65
rng_sigma_tol_fla g 161 Range sigma tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 66
rng_vld_flag 162 Range validity flag. 0 => Invalid 1 => Valid Unsigned Integer –1 N/A 0 or 1 67
rng_config_flag 163 Range configuration change flag. 0 => Changed 1 => Unchanged Unsigned Integer –1 N/A 0 or 1 68
rng_hw_flag 164 Ranging hardware status flag. 0 => Bad 1 => Good Unsigned Integer –1 N/A 0 or 1
time_tag_corr_flag 165 Time tag correction flag. Indicates results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
type_time_corr_fla g 166 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigne d Integer –1 N/A 0 to 3
dop_mode_corr_fl ag 167 Doppler mode correction flag. Indicates the results of the validation of the doppler mode. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
ul_stn_corr_flag 168 Uplink station correction flag. Indicates the results of the validation of the uplink station. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
chop_start_num 169 Chop Start. The first component chopped. Unsigne d Integer –1 N/A 0 to 25 16
rng_meas_type 170 Range Measurement Type. Type of sequential measurement. 0 => ranging measurement 1 => calibration Unsigne d Integer –1 N/A 0 or 1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
stn_cal_corr_flag 171 Station calibration correction flag. Indicates result of validation of station calibration values. 0 => unable to correct 1 => validated, no change 2 => validated, changed ul_stn_cal 3 => validated, changed dl_stn_cal 4 => validated, changed both ul_stn_cal and dl_stn_cal 5 => validated, changed round-trip stn_cal Unsigne d Integer –1 N/A 0 to 5
reserve6 172 Reserved. Six bytes. Unsigne d Integer –6 N/A 0
3.1.5.2.3 Downlink PN Ranging Phase CHDO (Data Type 5)

The Downlink PN Ranging Phase CHDO is defined in Table 3-15.

Table 3-15. Downlink PN Ranging Phase CHDO (Data Type 5) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
chdo_type 0 Type attribute of the downlink PN ranging phase data CHDO. CHDO contains binary data. Unsigned Integer –2 N/A 10
chdo_length 2 Length attribute of the downlink PN ranging phase data CHDO value field. Number of bytes after this item. Unsigned Integer –2 bytes 258
stn_cal 4 Station calibration value. (Two-way) Value includes the equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 24
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
dl_stn_cal 12 Downlink station calibration value. Value includes the downlink equipment in the path, but not the Z-height correction. (0.0 if not measured.) IEEE Double Range Units / 0.01 RU 0.0 to 1.8e5 10, 24
dl_cal_freq 20 Downlink calibration frequency. Frequency the calibration was done at. IEEE Double Sky level Hz / 1 mHz 2.2e9 to 32.3e9
cal_std_dev 28 Standard deviation of IEEE Range 0.0 to 24
station calibration value. Single Units / 1.8e5
For stn_cal and dl_stn_cal. 0.01 RU
cal_pts 32 Calibration points. Number of measurements made in computing station calibration values (stn_cal, dl_stn_cal, and cal_std_dev). Unsigned Integer –2 N/A 0 to 65,535
dl_rng_phs 34 Measured range phase. Range phase. IEEE Double Range Units / 0.01 RU 0.0 to 230 11, 24
figure_merit 42 Figure of Merit. Rating of the measured range value. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 28
rng_resid 46 Range residual. Measured range minus predicted range. IEEE Double Range Units / 0.01 RU -230 to 230 29
drvid 54 DRVID. DRVID measured using doppler data from carrier. IEEE Double Range Units / 0.01 RU -230 to 230 30
rtlt 62 Round trip light time. Predicted value. IEEE Single Seconds / 0.1 sec 0.0 to 86,400. 0
pcn0 66 Pc/N0. Carrier power to noise spectral density ratio. Has a value of -300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz 0.0 to 90.0, -300.0
pcn0_resid 70 Pc/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
pdn0 74 Pd/N0. Data power to noise spectral density ratio. Has a value of -300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz 0.0 to 90.0, -300.0 25
pdn0_resid 78 Pd/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
prn0 82 Pr/N0. Ranging power to noise spectral density ratio. Has a value of –300.0 if no signal. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0, -300.0
prn0_resid 86 Pr/N0 residual. Actual value minus predicted value. IEEE Single dB-Hz / 0.1 dB-Hz -90.0 to 90.0
system_noise_tem p 90 System Noise Temperature. IEEE Single K (degrees Kelvin) / 0.1 K 0.1 to 2000.0
state_subcode1 94 Subcode #1 code state. Position in the subcode at the time tag. Unsigned Integer –1 N/A 0 to 63 19
state_subcode2 95 Subcode #2 code state. Position in the subcode at the time tag. Unsigned Integer –1 N/A 0 to 63 19
state_subcode3 96 Subcode #3 code state. Position in the subcode at the time tag. Unsigned Integer –1 N/A 0 to 63 19
state_subcode4 97 Subcode #4 code state. Position in the subcode at the time tag. Unsigned Integer –1 N/A 0 to 63 19
state_subcode5 98 Subcode #5 code state. Position in the subcode at the time tag. Unsigned Integer –1 N/A 0 to 63 19
state_subcode6 99 Subcode #6 code state. Position in the subcode at the time tag. Unsigned Integer –1 N/A 0 to 63 19
pn_clk_phs 100 PN chip clock phase. Position in the chip at the time tag. IEEE Double Cycles / 1 μcycle 0.0 to 1.0 19
carr_loop_type 108 Carrier loop type. Unsigned Integer –1 N/A 1 to 3 53
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
snt_flag 109 SNT measurement flag. 0 => SNT value is the predicted value 1 => SNT value is the measured value Unsigned Integer –1 N/A 0 or 1
carr_resid_wt 110 Carrier residual weight. (Weight value applied to residual phase error in carrier tracking; suppressed carrier weight is 1.0 minus this value.) IEEE Single N/A 0.0 to 1.0 27
template_id 114 Template ID. Ranging configuration file ID, or the name of the PN pattern if configured by operator directive. ASCII –20 N/A ASCII string
invert 134 Invert. Inverted implies that the polarity of the correlation reference is the invert of what was transmitted. 0 => not inverted 1 => inverted Unsigned Integer –1 N/A 0 or 1 52
correl_type 135 Correlation type. Unsigned N/A 0 or 1
0 => squarewave Integer –1
1 => sinewave
int_time 136 Integration time. Unsigned Seconds 1 to 232
Timethat the signal was Integer –4 /1 –1
integrated over. second
clk_divider 140 Clock divider. Value that ranging reference frequency is divided by to get chip rate. Unsigned Integer –1 N/A 1 to 64 20
len_subcode1 141 Subcode #1 length. A value of 0 implies no subcode. Unsigned Integer –1 Chips / 1 chip 0 to 64 21
len_subcode2 142 Subcode #2 length. A value of 0 implies no subcode. Unsigned Integer –1 Chips / 1 chip 0 to 64 21
len_subcode3 143 Subcode #3 length. A value of 0 implies no subcode. Unsigned Integer –1 Chips / 1 chip 0 to 64 21
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
len_subcode4 144 Subcode #4 length. A value of 0 implies no subcode. Unsigned Integer –1 Chips / 1 chip 0 to 64 21
len_subcode5 145 Subcode #5 length. A value of 0 implies no subcode. Unsigned Integer –1 Chips / 1 chip 0 to 64 21
len_subcode6 146 Subcode #6 length. A value of 0 implies no subcode. Unsigned Integer –1 Chips / 1 chip 0 to 64 21
op_subcode1 147 Operation #1. Logical operation between the accumulated pattern and the next subcode. 0 => AND 1 => OR 2 => XOR 3 => Majority Vote Unsigned Integer –1 N/A 0 to 3
op_subcode2 148 Operation #2. (See Item op_subcode1) Unsigned Integer –1 N/A 0 to 3
op_subcode3 149 Operation #3. (See Item op_subcode1) Unsigned Integer –1 N/A 0 to 3
op_subcode4 150 Operation #4. (See Item op_subcode1) Unsigned Integer –1 N/A 0 to 3
op_subcode5 151 Operation #5. (See Item op_subcode1) Unsigned Integer –1 N/A 0 to 3
def_subcode1 152 Subcode #1 component value. Definition of the subcode. Unsigned Integer –8 N/A 0 to 264-1 21
def_subcode2 160 Subcode #2 component value. Definition of the subcode. Unsigned Integer –8 N/A 0 to 264-1 21
def_subcode3 168 Subcode #3 component value. Definition of the subcode. Unsigned Integer –8 N/A 0 to 264-1 21
def_subcode4 176 Subcode #4 component value. Definition of the subcode. Unsigned Integer –8 N/A 0 to 264-1 21
def_subcode5 184 Subcode #5 component value. Definition of the subcode. Unsigned Integer –8 N/A 0 to 264-1 21
def_subcode6 192 Subcode #6 component value. Definition of the subcode. Unsigned Integer –8 N/A 0 to 264-1 21
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
pn_code_length 200 PN Code Length. Unsigned PN 2 to 22
Integer –4 chips / 1 11,000,
chip 000
rcv_inphs_time_year 204 Receive In-phase time – year. Year of the time of zero phase on downlink range signal correlation. Unsigned Integer –2 N/A 1958 to 3000 75
rcv_inphs_time_doy 206 Receive In-phase time – day of year. Day of year of the time of zero phase on downlink range signal correlation. Unsigned Integer –2 N/A 1 to 366 75
rcv_inphs_time_sec 208 Receive In-phase time – seconds of day. Seconds of day of the time of zero phase on downlink range generation. IEEE Double Seconds / 1 μsec 0.0000 00 to 86,400. 999999 75
exc_scalar_num 216 Exciter Scalar Numerator. Numerator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigned Integer –4 N/A 1 to 232-1 17
exc_scalar_den 220 Exciter Scalar Denominator. Denominator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigned Integer –4 N/A 1 to 232-1 17
rng_cycle_time 224 Ranging cycle time. Time to complete one cycle of ranging code. IEEE Double Range Units / 0.01 RU 0.0 to 1.0e9 23, 24
inphs_correl 232 In phase correlation value. The in phase value of the clock component correlation. IEEE Single N/A -1.000e8 to 1.000e8
quad_phs_correl 236 Quadrature phase correlation value. The quadrature phase value of the clock component correlation. IEEE Single N/A -1.000e8 to 1.000e8
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
metrics_vld_flag 240 Metrics validity flag. Validity of the Range Residual (rng_resid) and DRVID (drvid) measurements. 0 => Invalid (No uplink data available) 1 => Invalid (Other reasons) 2 => Valid Unsigned Integer –1 N/A 0 to 2 70
correl_vld_flag 241 Correlation validity flag. 0 => Invalid 1 => Valid Unsigned Integer –1 N/A 0 or 1 56
rng_resid_tol_flag 242 Range residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 63
drvid_tol_flag 243 DRVID tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 64
prn0_resid_tol_fla g 244 Pr/N0 residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 65
rng_sigma_tol_fla g 245 Range sigma tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer –1 N/A 0 or 1 66
rng_vld_flag 246 Range validity flag. 0 => Invalid 1 => Valid Unsigned Integer –1 N/A 0 or 1 67
rng_config_flag 247 Range configuration change flag. 0 => Changed 1 => Unchanged Unsigned Integer –1 N/A 0 or 1 68
rng_hw_flag 248 Ranging hardware status flag. 0 => Bad 1 => Good Unsigned Integer –1 N/A 0 or 1
rng_meas_type 249 Range Measurement Type. Type of PN measurement. 0 => spacecraft measurement 1 => calibration Unsigned Integer –1 N/A 0 or 1
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
time_tag_corr_flag 250 Time tag correction flag. Indicates results of validation of the block time Unsigned Integer –1 N/A 0 to 2
tag. 0 => no validation
attempted 1 => validated, no change 2 => validated, changed
type_time_corr_fla g 251 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigned Integer –1 N/A 0 to 3
dop_mode_corr_fl ag 252 Doppler mode correction flag. Indicates the results of the validation of the doppler mode. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigned Integer –1 N/A 0 to 2
ul_stn_corr_flag 253 Uplink station correction flag. Indicates the results of the validation of the uplink station. 0 => not applicable or novalidation attempted 1 => validated, no change 2 => validated, changed Unsigned Integer –1 N/A 0 to 2
Identifier Byte Offset Item Name and Description Format Units/ Precisio n Range Notes
stn_cal_corr_flag 254 Station calibration correction flag. Indicates result of validation of station calibration values. 0 => unable to correct 1 => validated, no change 2 => validated, changed ul_stn_cal 3 => validated, changed dl_stn_cal 4 => validated, changed both ul_stn_cal and dl_stn_cal 5 => validated, changed round-trip stn_cal Unsigned Integer-1 N/A 0 to 5
Reserve1 255 Reserved. One byte. Unsigned Integer –1 N/A 0
Reserve6 256 Reserved. Six bytes. Unsigned Integer-6 N/A 0
3.1.5.3 Derived Data CHDOs

There are seven derived data CHDOs: Doppler Count (data type 6), Sequential Range (data type 7), Angle (data type 8), DRVID (data type 11), PN Range (data type 14), Tone Range (data type 15), Carrier Frequency Observable (data type 16), and Total Count Phase Observable (data type 17). Their formats and contents are specified in sections 3.1.5.3.1 to 3.1.5.3.7

3.1.5.3.1 Doppler Count CHDO (Data Type 6)

The Doppler Count CHDO is defined in Table 3-16. It is generated only for non-UPLDTT antennas.

Table 3-16. Doppler Count CHDO (Data Type 6) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the Doppler Count data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the Doppler Count data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 56
ref_rcv_type 4 Reference receiver type. 0 => Unknown 2 => MFR Unsigne d Integer –1 N/A 0 or 2
reserve1a 5 Reserved. Unsigne N/A 0
One byte. d Integer
–1
sampl_interval 6 Sample interval. Interval between points. Value of –1.0 indicates interval is unknown. IEEE Single Seconds / 0.1 second -1.0, 1.0 to 60.0 84
rcv_sig_lvl 10 Received signal level. Carrier power or data power (if suppressed carrier tracking). (-300.0 if not valid.) IEEE Single dBm / 0.1 dBm -300.0, -190.0 to – 45.0 58
ul_freq 14 Uplink frequency. Uplink frequency value used in the Doppler computation at time tag. Also called the Doppler Reference Frequency. IEEE Double Hz / 1 mHz 2.0e9 to 34.7e9 34
dop_cnt_bias _freq 22 Doppler count bias frequency. Bias value used in Doppler Count measurement. IEEE Double Hz / 1 mHz -10.0e6 to 10.0e6 34
dop_cnt 30 Doppler Count. IEEE Double cycles / 1 mcycle 0.000 to 242 / 1000 34
dop_pseudo_re sid 38 Doppler Pseudo Residual. Actual minus predicted value. IEEE Double Hz / 1 mHz -228 / 1000 to 228 / 1000
time_tag_corr_ flag 46 Time tag correction flag. Indicates the results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
type_time_corr _flag 47 Type of time tag correction flag. Indicates what type of time tag correction was made. Unsigne d Integer –1 N/A 0 to 3
0 => no correction
1 => Year correction
2 => DOY correction
3 => Both Year and DOY
correction
dop_mode_corr _flag 48 Doppler mode correction flag. Indicates the results of validation of the Doppler mode. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
ul_stn_corr_fla g 49 Uplink station correction flag. Indicates the results of validation of the uplink station. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
dl_band_corr_f lag 50 Downlink frequency band correction flag. Indicates the results of validation of downlink band for the 26m stations only. 0 => not applicable or no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
dop_vld_flag 51 Doppler Validity Flag. 0 => Valid 1 => Invalid. Unsigne d Integer –1 N/A 0 or 1 89
reserve8 52 Reserved. Unsigne N/A 0
Eight bytes. d Integer
–8
3.1.5.3.2 Sequential Range CHDO (Data Type 7)

The Sequential Range CHDO is defined in Table 3-17.



Table 3-17. Sequential Range CHDO (Data Type 7) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the range data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the range data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 186
ul_stn_cal 4 Uplink station calibration value. Invalid indicated by value of – 1.0. IEEE Double Range Units / 0.01 RU -1.0, 0.0 to 1.8e5 24, 40
dl_stn_cal 12 Downlink station calibration value. Invalid indicated by value of –1.0. IEEE Double Range Units / 0.01 RU -1.0, 0.0 to 1.8e5 24, 41
meas_rng 20 Measured range value. Does not include compensation for station calibration and other adjustments. Invalid is indicated by value of -1.0. IEEE Double Range Units, modulo rng_mod ulo / 0.01 RU -1.0, 0.0 to 230 24, 38
rng_obs 28 Range observable. Includes all measurement adjustments (station calibration, time tag adjustments, spacecraft delay, and Z-height). Invalid is indicated by value of -1.0. IEEE Double Range Units, modulo rng_modulo / 0.01 RU -1.0, 0.0 to 230 24, 39
rng_obs_dl 36 Downlink range observable. Includes all measurement adjustments (station calibration, time tag adjustments, spacecraft delay, and Z-height). A value of -1.0 indicates invalid. IEEE Double Range Units, modulo rng_modulo / 0.01 RU -1.0, 0.0 to 230 24, 76
clock_waveform 44 Uplink clock waveform type. Unsigne N/A 0 or 1
0 => squarewave d Integer
1 => sinewave -1
chop_start_num 45 Chop Start. The first component chopped. Unsigne d Integer –1 N/A 0 to 25 16
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
figure_merit 46 Figure of Merit. Rating of the measured range value. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 28
drvid 50 DRVID. DRVID measured using phase data from carrier. IEEE Double Range Units / 0.01 RU -230 to 230 24, 30
rtlt 58 Round trip light time. Predicted value. IEEE Single Seconds / 0.1 sec 0.0 to 86,400.0
prn0 62 Pr/N0. Ranging power to noise spectral density ratio. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0
transmit_pwr 66 Transmitter power. IEEE Single W / 0.1 W 0.0 to 500,000. 0
invert 70 Invert. Inverted implies that the polarity of the correlation reference is the invert of what was transmitted. 0 => not inverted 1 => inverted Unsigne d Integer –1 N/A 0 or 1
correl_type 71 Correlation type. 0 => squarewave 1 => sinewave Unsigne d Integer –1 N/A 0 or 1
t1 72 T1 setting. Unsigne d Integer –2 Seconds / 1 sec 1 to 3600 12
t2 74 T2 setting. Unsigne d Integer –2 Seconds / 1 sec 1 to 1800 13
t3 76 T3 setting. Unsigne d Integer –2 Seconds / 1 sec 0 to 1800 14
first_comp_num 78 First component number. Unsigne d Integer –1 N/A 1 to 24 15
last_comp_num 79 Last component number. Unsigne d Integer –1 N/A 1 to 24 15
chop_comp_num 80 Chop component number. This is the component used to chop the other Unsigne d Integer –1 N/A 0 to 10 15, 16
components.
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
num_drvid 81 Number of DRVID measurements. Unsigne d Integer –1 N/A 0 to 255
transmit_inphs _time 82 Transmit In-phase time. Offset from time tag of time of zero phase on uplink range signal generation. IEEE Single Seconds / 1 μsec -86,400. 000000 to 86,400.0 00000 59
rcv_inphs_time 86 Receive In-phase time. Offset from time tag of time of zero phase on downlink range signal correlation. IEEE Single Seconds / 1 μsec -86,400. 000000 to 86,400.0 00000 59
carr_sup_rng _modul 90 Carrier suppression by ranging modulation. Amount carrier power is reduced by ranging modulation. IEEE Single dB / 0.1 dB 0.0 to 15.0
exc_scalar_num 94 Exciter Scalar Numerator. Numerator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
exc_scalar_den 98 Exciter Scalar Denominator. Denominator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
rng_cycle_time 102 Range cycle time. Time, in seconds, of one complete cycle of the ranging signal. IEEE Double Seconds / 0.1 sec 4.0 to 504,536. 0 18
rng_modulo 110 Range modulo value. Range measurement modulo (ambiguity). Unsigned Integer –4 Range Units / 1 RU 1 to 230 37
inphs_correl 114 In phase correlation value. The in phase value of the clock component correlation. IEEE Single N/A -1.000e8 to 1.000e8
quad_phs_correl 118 Quadrature phase correlation value. The quadrature phase value of the clock component correlation. IEEE Single N/A -1.000e8 to 1.000e8
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
ul_freq 122 Uplink frequency. Uplink frequency at time tag. Set to 0.0 if unavailable. IEEE Double Hz / 1 mHz 0.0, 2.0e9 to 34.4e9 42
rng_type 130 Range measurement type. Type of sequential Unsigned Integer –1 N/A 0 or 1
measurement.
0 => Ranging measurement 1 => Calibration
reserve1a 131 Reserved. One byte. Unsigne d Integer –1 N/A 0
rng_noise 132 Range noise. Invalid indicated by value of -1.0. IEEE Single Range Units / 0.01 RU -1.0, 0.0 to 230 43
rng_prefit_resid 136 Range pre-fit residual. Observed range minus predicted range. IEEE Double Range Units / 0.01 RU -230 to 230 24, 29, 86
rng_dl_prefit_resi d 144 Downlink range pre-fit residual. Observed range minus predicted range. IEEE Double Range Units / 0.01 RU -230 to 230 24, 29, 86
rng_prefit_resid_v ld_flag 152 Range pre-fit residual validity indicator. 0 => Invalid pre-fit residual data 1 => Valid pre-fit residual data Unsigne d Integer1 N/A 0 or 1 86
rng_dl_prefit_resi d_vld_flag 153 Downlink range pre-fit residual validity indicator. 0 => Invalid pre-fit residual data Unsigned Integer-1 N/A 0 or 1 86
1 => Valid pre-fit residual data
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rng_resid_tol_valu e 154 Range residual tolerance value. Value used for setting Range residual tolerance flag. Provided by customer. Applies to both rng_prefit_resid and rng_dl_prefit_resid; not applicable if rng_prefit_resid_vld_flag and rng_dl_prefit_resid_vld_flag are 0. IEEE Single Range Units / 0.01 RU -230 to 230 24, 63
drvid_tol_value 158 DRVID tolerance value. Value used for setting DRVID tolerance flag. Provided by customer. IEEE Single Range Units / 0.01 RU -230 to 230 24, 64
prn0_resid_tol_val ue 162 Pr/N0 residual tolerance value. Value used for setting Pr/N0 residual tolerance flag. Provided by customer. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0 65
rng_sigma_tol_val ue 166 Range sigma tolerance value. Value used for setting Range sigma tolerance flag. Provided by customer. Not applicable if rng_noise is 1.0. IEEE Single Range Units / 0.01 RU 0.0 to 230 43, 66
fom_tol_value 170 Figure of Merit tolerance value. Value used in setting of Range Validity flag. Provided by customer. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 28
rng_resid_tol_flag 174 Range residual tolerance flag. Not applicable if rng_prefit_resid_vld_flag and rng_dl_prefit_resid_vld_flag are 0. 0 => Out of tolerance 1 => In tolerance Unsigned Integer-1 N/A 0 or 1 63
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
drvid_tol_flag 175 DRVID tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer-1 N/A 0 or 1 64
prn0_resid_tol_fla g 176 Pr/N0 residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer-1 N/A 0 or 1 65
rng_sigma_tol_fla g 177 Range sigma tolerance flag. Not applicable if rng_noise is set to -1.0. 0 => Out of tolerance 1 => In tolerance Unsigned Integer-1 N/A 0 or 1 66
rng_vld_flag 178 Range validity flag. 0 => Invalid 1 => Valid Unsigned Integer-1 N/A 0 or 1 67
rng_config_flag 179 Range configuration change flag. 0 => Changed 1 => Unchanged Unsigned Integer-1 N/A 0 or 1 68
stn_cal_corr_flag 180 Station calibration correction flag. Indicates results of validation of the station calibration value. 0 => unable to correct 1 => validated, no change 2 => validated, changed uplink 3 => validated, changed downlink 4 => validated, changed both uplink and downlink Unsigne d Integer –1 N/A 0 to 4
rng_chan_num 181 Ranging channel number. Only provided by 26m antennas. Unsigne d Integer –1 N/A 1 or 2
time_tag_corr_flag 182 Time tag correction flag. Indicates the results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
type_time_corr_fla g 183 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigne d Integer –1 N/A 0 to 3
reserve6 184 Reserved. Unsigne N/A 0
Six bytes. d Integer
–6
3.1.5.3.3 Angle CHDO (Data Type 8)

The Angle CHDO is defined in Table 3-18. The Angle CHDO applies only to the 26m antennas.

Table 3-18. Angle CHDO (Data Type 8) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the angle data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the angle data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 34
source_type 4 Source type. 0 => unknown 2 => MPA (26m), or MTA Unsigne d Integer –1 N/A 0 or 2
ang_type 5 Angles Type. 0 => Unknown 1 => Azimuth / Elevation 2 => Hour angle / Declination 3 => X/Y (where +X is East) 4 => X/Y (where +X is South) Unsigned Integer –1 N/A 0 to 4
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
ang_vld_flag 6 Angles validity flag. 0 => Invalid 1 => Valid Unsigne d Integer –1 N/A 0 or 1 57
ang_mode 7 Angle Mode. 0 => Auto Track 1 => Manual Aided 2 => Computer 3 => Sidereal 4 => Brake Unsigne d Integer –1 N/A 0 to 4
conscan_mode 8 Conscan Mode. 0 => Conscan off 1 => Closed loop 2 => Open loop Unsigne d Integer –1 N/A 0 to 2
reserve1 9 Reserved. One byte. Unsigne d Integer –1 N/A 0
ang1 10 Angle 1. Azimuth, hour angle, or X. IEEE Single Deg / 0.1 deg -90.0 to 90.0
ang2 14 Angle 2. Elevation, declination, or Y. IEEE Single Deg / 0.1 deg -90.0 to 90.0
ang1_pseudo _resid 18 Angle 1 pseudo-residual. Actual minus predicted. IEEE Single Deg / 0.1 deg -90.0 to 90.0
ang2_pseudo _resid 22 Angle 2 pseudo-residual. Actual minus predicted. IEEE Single Deg / 0.1 deg -90.0 to 90.0
time_tag_corr_flag 26 Time tag correction flag. Indicates the results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
type_time_corr_fla g 27 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigne d Integer –1 N/A 0 to 3
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
reserve2 28 Reserved. Two bytes. Unsigne d Integer –2 N/A 0
reserve8 30 Reserved. Eight bytes. Unsigne d Integer –8 N/A 0
3.1.5.3.4 DRVID CHDO (Data Type 11)

The DRVID CHDO is generated for sequential and PN ranging (not tone ranging) from UPL-DTT antennas and is defined in Table 3-19.

Table 3-19. DRVID CHDO (Data Type 11) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the DRVID data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the DRVID data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 38
drvid_type 4 DRVID type. 0 => Unknown 1 => Sequential 2 => PN Unsigne d Integer –1 N/A 0 to 2
drvid_pts 5 DRVID points. Unsigne d Integer –1 N/A 0 to 255
drvid 6 DRVID measurement. IEEE Double Range Units / 0.01 RU -230 to 230 24, 30, 79
prn0 14 Pr/N0. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0
drvid_noise 18 DRVID noise. Invalid indicated by value of -1.0. IEEE Single Range Units / 0.01 RU -1.0, 0.0 to 230 24, 44
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
drvid_tol_value 22 DRVID tolerance value. Value used for setting DRVID tolerance flag. Provided by customer. IEEE Single Range Units / 0.01 RU -230 to 230 24, 64
prn0_resid_tol_val ue 26 Pr/N0 residual tolerance value. Value used for setting Pr/N0 residual tolerance flag. Provided by customer. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0 65
reserve1 30 Reserved. One byte. Unsigne d Integer –1 N/A 0
drvid_tol_flag 31 DRVID tolerance flag. 0 => Out of Tolerance 1 => In tolerance Unsigne d Integer1 N/A 0 or 1 64
prn0_resid_tol_fla g 32 Pr/N0 residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigne d Integer1 N/A 0 or 1 65
drvid_noise_pts 33 DRVID noise points. Number of points used in DRVID noise computation. Unsigne d Integer –1 N/A 0 to 200
reserve8 34 Reserved. Eight bytes. Unsigne d Integer –8 N/A 0
3.1.5.3.5 PN Range CHDO (Data Type 14)

The PN Range CHDO is defined in Table 3-20.

Table 3-20. PN Range CHDO (Data Type 14) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the PN range data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the PN range data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 204
ul_stn_cal 4 Uplink station calibration value. Invalid indicated by value of –1.0. IEEE Double Range Units / 0.01 RU -1.0, 0.0 to 1.8e5 24, 40
dl_stn_cal 12 Downlink station calibration value. Invalid indicated by value of –1.0. IEEE Double Range Units / 0.01 RU -1.0, 0.0 to 1.8e5 24, 41
meas_rng 20 Measured range value. Does not include compensation for station calibration and other adjustments. Invalid is indicated by value of -1.0. IEEE Double Range Units, modulo rng_modulo / 0.01 RU -1.0, 0.0 to 230 24, 45, 46
rng_obs_dl 28 Downlink range observable. Includes measurement adjustments (station calibration, time tag offsets, spacecraft delay, and Z-height). Invalid is indicated by value of -1.0. IEEE Double Range Units, modulo rng_modulo / 0.01 RU -1.0, 0.0 to 230 24, 76
figure_merit 36 Figure of Merit. Rating of the measured range value. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 28
drvid 40 DRVID. DRVID measured using doppler data from carrier IEEE Double Range Units / 0.01 RU -230 to 230 30, 24, 79
rtlt 48 Round trip light time. Predicted value. IEEE Single Seconds / 0.1 sec 0.0 to 86,400.0
prn0 52 Pr/N0. Ranging power to noise spectral density ratio. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0
transmit_pwr 56 Transmitter power. IEEE Single W / 0.1 W 0.0 to 500,000.0
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
invert 60 Invert. Inverted implies that the polarity of the correlation reference is the invert of Unsigne d Integer –1 N/A 0 or 1 52
what was transmitted.
0 => not inverted
1 => inverted
correl_type 61 Correlation type. 0 => squarewave 1 => sinewave Unsigne d Integer –1 N/A 0 or 1
clk_divider 62 Clock divider. Value that ranging reference frequency is divided by to get chip Unsigne d Integer –1 N/A 1 to 64 20
rate.
len_subcode1 63 Subcode #1 length. Unsigne Chips / 0 to 64 21
A value of 0 implies no d Integer 1 chip
subcode. –1
len_subcode2 64 Subcode #2 length. Unsigne Chips / 0 to 64 21
A value of 0 implies no d Integer 1 chip
subcode. –1
len_subcode3 65 Subcode #3 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
len_subcode4 66 Subcode #4 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
len_subcode5 67 Subcode #5 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
len_subcode6 68 Subcode #6 length. A value of 0 implies no subcode. Unsigne d Integer –1 Chips / 1 chip 0 to 64 21
op_subcode1 69 Operation #1. Logical operation between the accumulated pattern and the next subcode. 0 => AND 1 => OR 2 => XOR 3 => Majority Vote Unsigne d Integer –1 N/A 0 to 3
op_subcode2 70 Operation #2. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
op_subcode3 71 Operation #3. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
op_subcode4 72 Operation #4. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
op_subcode5 73 Operation #5. (See Item op_subcode1) Unsigne d Integer –1 N/A 0 to 3
def_subcode1 74 Subcode #1 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode2 82 Subcode #2 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode3 90 Subcode #3 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode4 98 Subcode #4 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode5 106 Subcode #5 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
def_subcode6 114 Subcode #6 component value. Definition of the subcode. Unsigne d Integer –8 N/A 0 to 264-1 21
pn_code_length 122 PN Code Length. Unsigne d Integer –4 PN chips 2 to 11,000,00 0 22
transmit_inphs_ti me 126 Transmit In-phase time. Offset from time tag of time of zero phase on uplink range signal generation. IEEE Single Seconds / 1 μsec -86,400.00 0000 to 86,400.00 0000 59
rcv_inphs_time 130 Receive In-phase time. Offset from time tag of time of zero phase on downlink range signal correlation. IEEE Single Seconds / 1 μsec -86,400.00 0000 to 86,400.00 0000 59
carr_sup_rng _modul 134 Carrier suppression by ranging modulation. Reduction in carrier power due to ranging modulation. IEEE Single dB / 0.1 dB 0.0 to 15.0
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
exc_scalar_num 138 Exciter Scalar Numerator. Numerator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
exc_scalar_den 142 Exciter Scalar Denominator. Denominator of multiplier that is used to generate ranging reference signal from uplink sky frequency. Unsigne d Integer –4 N/A 1 to 232-1 17
rng_cycle_time 146 Range cycle time. Time, in Range Units, of one complete cycle of the ranging signal. IEEE Double Range Units / 0.01 RU 0.0 to 1.0e9 23, 24
rng_modulo 154 Range modulo value. Range measurement modulo (ambiguity). Unsigned Integer –4 Range Units / 1 RU 0 to 230 45
rng_type 158 Range measurement type. Type of PN measurement. 0 => measurement 1 => calibration Unsigne d-1 N/A 0 or 1
reserve1a 159 Reserved. One byte. Unsigne d-1 N/A 0
rng_noise 160 Range noise. Invalid indicated by value of -1.0. IEEE Single Range Units / 0.01 RU -1.0, 0.0 to 230 43
rng_dl_prefit_resi d 164 Downlink range pre-fit residual. Observed range minus predicted range. IEEE Double Range Units / 0.01 RU -230 to 230 24, 29, 86
rng_dl_prefit_resi d_vld_flag 172 Downlink range pre-fit residual validity indicator. 0 => Invalid pre-fit residual data 1 => Valid pre-fit residual data Unsigne d Integer1 N/A 0 or 1 86
clock_waveform 173 Uplink clock waveform type. Unsigne N/A 0 or 1
0 => squarewave d Integer
1 => sinewave -1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rng_resid_tol_valu e 174 Range residual tolerance value. Value used for setting Range residual tolerance flag. Provided by customer. Applies to rng_dl_prefit_resid; not applicable if rng_dl_prefit_resid_vld_fla g is 0. IEEE Single Range Units / 0.01 RU -230 to 230 24, 63
drvid_tol_value 178 DRVID tolerance value. Value used for setting DRVID tolerance flag. Provided by customer. IEEE Single Range Units / 0.01 RU -230 to 230 24, 64
prn0_resid_tol_val ue 182 Pr/N0 residual tolerance value. Value used for setting Pr/N0 residual tolerance flag. Provided by customer. IEEE Single dB-Hz / 0.1 dB-Hz -10.0 to 90.0 65
rng_sigma_tol_val ue 186 Range sigma tolerance value. Value used for setting Range sigma tolerance flag. Provided by customer. Not applicable if rng_noise is set to -1.0. IEEE Single Range Units / 0.01 RU 0.0 to 230 43, 66
fom_tol_value 190 Figure of Merit tolerance value. Value used in setting of Range Validity flag. Provided by customer. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 28
rng_resid_tol_flag 194 Range residual tolerance flag. Not applicable if rng_dl_prefit_resid_vld_fla g is 0. 0 => Out of tolerance 1 => In tolerance Unsigned Integer-1 N/A 0 or 1 63
drvid_tol_flag 195 DRVID tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer-1 N/A 0 or 1 64
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
prn0_resid_tol_fla g 196 Pr/N0 residual tolerance flag. 0 => Out of tolerance 1 => In tolerance Unsigned Integer-1 N/A 0 or 1 65
rng_sigma_tol_fla g 197 Range sigma tolerance flag. Not applicable if rng_noise is set to -1.0. Unsigned Integer-1 N/A 0 or 1 66
0 => Out of tolerance
1 => In tolerance
rng_vld_flag 198 Range validity flag. 0 => Invalid 1 => Valid Unsigned Integer-1 N/A 0 or 1 67
rng_config_flag 199 Range configuration change flag. 0 => Changed 1 => Unchanged Unsigned Integer-1 N/A 0 or 1 68
stn_cal_corr_flag 200 Station calibration correction flag. Indicates results of validation of the station calibration value. 0 => unable to correct 1 => validated, no change 2 => validated, changed uplink 3 => validated, changed downlink 4 => validated, changed both uplink and downlink Unsigne d Integer –1 N/A 0 to 4
reserve1b 201 Reserved. One byte. Unsigne d Integer –1 N/A 0
Reserve6 202 Reserved. Six bytes. Unsigne d Integer6 N/A 0

3.1.5.3.6 Tone Range CHDO (Data Type 15)

The Tone Range CHDO is defined in Table 3-21. The Tone Range CHDO applies only to the non-UPL-DTT antennas.

Table 3-21. Tone Range CHDO (Data Type 15) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the tone range data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the tone range data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 50
source_type 4 Source type. 0 => Unknown 2 => MPA (26m), MTA Unsigne d Integer –1 N/A 0 or 2
mjr_tone_freq 5 Major tone frequency. 0 => Not used 1 => 20 kHz 2 => 100 kHz 3 => 500 kHz Unsigne d Integer –1 N/A 0 to 3
mnr_tone_freq 6 Minor tone frequency. 0 => not used 1 => 10 Hz Unsigne d Integer –1 N/A 0 or 1
rng_prefit_resid_v ld_flag 7 Tone range pre-fit residual validity indicator. 0 => Invalid pre-fit residual data 1 => Valid pre-fit residual data Unsigne d Integer –1 N/A 0 or 1 86
meas_rng 8 Measured range value. Range as reported by the station; includes corrections for Z-height and station calibration IEEE Double nsec, modulo 232 / 0.1 nsec 0 to 232 -1 72
rng_obs 16 Range observable. Includes measurement adjustments (station calibration, spacecraft delay, and Z-height). Invalid is indicated by value of -1.0. IEEE Double nsec, modulo 232 / 0.1 nsec -1.0, 0 to 232 - 1 72
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
stn_cal 24 Station calibration. IEEE nsec / 0.0 to 72
Not currently reported by Double 0.1 nsec 1.8e5
station; value set to 0.0.
carr_pwr 32 Carrier power. IEEE Single dBm / 0.1 dBm -185.0 to –85.0
rng_prefit _resid 36 Tone Range pre-fit residual. Observed range minus predicted range. IEEE Double nsec / 0.1 nsec -227 to 227 86
ul_freq 44 Uplink frequency. Uplink frequency value also called Doppler Reference Frequency. IEEE Double Hz / 1 mHz 2.0e9 to 34.7e9 34
time_tag_corr_flag 52 Time tag correction flag. Indicates the results of validation of the block time tag. 0 => no validation attempted 1 => validated, no change 2 => validated, changed Unsigne d Integer –1 N/A 0 to 2
type_time_corr_fla g 53 Type of time tag correction flag. Indicates what type of time tag correction was made. 0 => no correction 1 => Year correction 2 => DOY correction 3 => Both Year and DOY correction Unsigne d Integer –1 N/A 0 to 3
3.1.5.3.7 Carrier Frequency Observable CHDO (Data Type 16)

The Carrier Frequency Observable CHDO is defined in Table 3-22.

Table 3-22. Carrier Frequency Observables CHDO (Data Type 16) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the Carrier Frequency Observables data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the Carrier Frequency Observables data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 Bytes 38 + 18 * num_ob s
ref_rcv_type 4 Reference receiver type. 0 => Unknown 1 => DTT 2 => MFR Unsigne d Integer –1 N/A 0 to 2
reserve1 5 Reserved. Unsigne N/A 0
One byte. d Integer
–1
carr_prefit_resid_ tol_value 6 Received carrier pre-fit residual tolerance value. Value used for setting received carrier pre-fit residual tolerance flag. Provided by customer. IEEE Single Hz / 1 mHz -1.0e6 to 1.0e6 62
reserve2 10 Reserved. Two bytes. Unsigne d Integer –2 N/A 0
dop_noise 12 Doppler noise. Invalid indicated by value of -1.0. IEEE Single Hz / 1 mHz -1.0, 0.0 to 1000.0 26
delta_ff 16 Delta-f/f. Valid only for UPL-DTT antennas. IEEE Double N/A -1.0 to 1.0 32
rcv_sig_lvl 24 Received signal level. Carrier power or data power (if suppressed carrier tracking). (-300.0 if not valid.) IEEE Single dBm / 0.1 dBm -300.0, -190.0 to –45.0 58
num_obs 28 Number of Observable measurements. Unsigne d Integer –2 N/A 1 to 100 33
obs_cnt_time 30 Observable count time. IEEE seconds / 0.1 to 33
Integration time of the single 0.1 sec 3600.0
observables.
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rcv_carr_obs 34, 52, …, 34 + 18 * (num_ob s – 1) Received Carrier observable. This measurement is part of a set of measurements that are repeated num_obs times. IEEE Double Sky level Hz / 1 mHz -32.3e9 to -2.0e9 35
carr_prefit_resid 42, 60, …, 42 + 18 * (num_ob s – 1) Received carrier pre-fit residual. Observed minus predicted. IEEE Single Hz / 1 mHz -1.0e6 to 1.0e6 86
carr_prefit_resid_ vld_flag 46, 64, …, 46 + 18 * (num_ob s – 1) Received carrier pre-fit residual validity indicator. 0 => Invalid pre-fit residual data 1 => Valid pre-fit residual data Unsigne d Integer –1 N/A 0 or 1 86
carr_prefit_resid_ tol_flag 47, 65, …, 47 + 18 * (num_ob s – 1) Received carrier pre-fit residual tolerance flag. 0 => Out of tolerance 1 => In tolerance 2 => Not applicable Unsigne d Integer –1 N/A 0 to 2 62, 86
reserve4 48, 66, …, 48 + 18 * (num_ob s – 1) Reserved. Four bytes. Unsigne d Integer –4 N/A 0
reserve8 34 + 18 * num_obs Reserved. Eight bytes. Unsigne d Integer -8 N/A 0
3.1.5.3.8 Total Count Phase Observable CHDO (Data Type 17)

The Total Count Phase Observable CHDO is defined in Table 3-23.

Table 3-23. Total Count Phase Observable CHDO (Data Type 17) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the Total Count Phase Observables data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the Total Count Phase Observables data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 50 + 22 * num_ob s
ref_rcv_type 4 Reference receiver type. 0 => Unknown 1 => DTT 2 => MFR Unsigne d Integer –1 N/A 0 to 2
reserve1 5 Reserved. Unsigne N/A 0
One byte. d Integer
–1
total_cnt_phs_p refit_resid_tol_ value 6 Total Count Phase pre-fit residual tolerance value. Value used for setting total count phase pre-fit residual tolerance flag. Provided by customer. IEEE Single Hz / 1 mHz -1.0e6 to 1.0e6 62
reserve2 10 Reserved. Unsigne N/A 0
Two bytes. d Integer
–2
dop_noise 12 Doppler noise. Invalid indicated by value of -1.0. IEEE Single Hz / 1 mHz -1.0, 0.0 to 1000.0 26
delta_ff 16 Delta-f/f. Valid only for UPL-DTT antennas. IEEE Double N/A -1.0 to 1.0 32
rcv_sig_lvl 24 Received signal level. Carrier power or data power (if suppressed carrier tracking). (-300.0 if not valid.) IEEE Single dBm / 0.1 dBm -300.0, -190.0 to –45.0 58
num_obs 28 Number of Observable measurements. Unsigne d Integer –2 N/A 1 to 100 33
obs_cnt_time 30 Observable count time. IEEE seconds / 0.1 to 33
Integration time of the Single 0.1 sec 3600.0
observables.
total_cnt_phs_s t_year 34 Total Count Phase observable start time year. Unsigne d Integer –2 N/A 1900 to 3000 36
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
total_cnt_phs_s t_doy 36 Total Count Phase observable start time day of year. Unsigne d Integer –2 N/A 1 to 366 36
total_cnt_phs_s t_sec 38 Total Count Phase observable start time seconds. IEEE Double Seconds / 0.01 sec 0.00 to 86,400.9 9 1, 36
total_cnt_phs _obs_hi 46, 68, …, 46 + 22 * (num_ob s – 1) Negative of Total Count Phase observable - High part phase data whole cycles. This measurement is part of a set of measurements that are repeated num_obs times. Unsigne d Integer –4 Total integer phase cycles divided by 232 0 to 232-1 8, 36
total_cnt_phs _obs_lo 50, 72, …, 50 + 22 * (num_ob s – 1) Negative of Total Count Phase observable - Low part phase data whole cycles. This measurement is part of a set of measurements that are repeated num_obs times. Unsigne d Integer –4 Total integer phase cycles modulo 232 0 to 232-1 8, 36
total_cnt_phs _obs_frac 54, 76, …, 54 + 22 * (num_ob s – 1) Negative of Total Count Phase observable – Fractional part phase data cycles. This measurement is part of a set of measurements that are repeated num_obs times. Unsigne d Integer –4 Fractiona l phase cycles multiplie d by 232 0 to 232-1 8, 36
total_cnt_phs_p refit_resid 58, 80, …, 58 + 22 * (num_ob s – 1) Total Count Phase pre-fit residual. Observed minus predicted. IEEE Single Hz / 1 mHz -1.0e6 to 1.0e6 86
total_cnt_phs_p refit_resid_vld_ flag 62, 84, …, 62 + 22 * (num_ob s – 1) Total Count Phase pre-fit residual validity indicator. 0 => Invalid pre-fit residual data 1 => Valid pre-fit residual data Unsigne d Integer –1 N/A 0 or 1 86
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
total_cnt_phs_p refit_resid_tol_ flag 63, 85, …, 63 + 22 * (num_ob s – 1) Total Count Phase pre-fit residual tolerance flag. 0 => Out of tolerance 1 => In tolerance 2 => Not applicable Unsigne d Integer –1 N/A 0 to 2 62, 86
reserve4 64, 86, …, 64 + 22 * (num_ob s – 1) Reserved. Four bytes. Unsigne d Integer –4 N/A 0
reserve8 46 + 22 * num_obs Reserved. Eight bytes. Unsigne d Integer -8 N/A 0
3.1.5.4 Interferometric Data CHDOs

There is one interferometric data CHDO: VLBI (data type 10). Its format and contents are specified in section 3.1.5.4.1.

3.1.5.4.1 VLBI CHDO (Data Type 10)

The VLBI CHDO is defined in Table 3-24.

Table 3-24. VLBI CHDO (Data Type 10) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the VLBI data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
chdo_length 2 Length attribute of the VLBI data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 96
clk_off_epoch _year 4 Clock offset epoch year. Unsigne d Integer –2 Years 1958 to 3000 78
clk_off_epoch _doy 6 Clock offset epoch DOY. Unsigne d Integer –2 Days 1 to 366 78
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
clk_off_epoch_sec 8 Clock offset epoch seconds. IEEE Double seconds / 0.1 msec 0.0000 to 1, 78
86,400.9
999
clk_off_1 16 Clock offset at first receiving antenna for scan. (UTC-station time) IEEE Single sec / 0.1 nsec 10.0e10 to 10.0e10
clk_off_2 20 Clock offset at second receiving antenna for scan. (UTC-station time) IEEE Single sec / 0.1 nsec – -10.0e10 to 10.0e10
phs_cal_flag 24 Phase calibration flag. 0 => unknown Unsigned Integer –1 N/A 0 to 5
1 => no calibration
2 => default calibration
3 => quasar calibration only 4 => spacecraft calibration only 5 => spacecraft and quasar calibration
chan_sampl_flag 25 Channel sampling flag. 1 => multiplexed 2 => dual-frequency combined Unsigned Integer –1 N/A 1 to 3
3 => 4 parallel channels
quasar_id 26 Quasar ID. Name of quasar used. ASCII – 12 N/A ASCII string
quasar_id_num 38 Quasar ID numeric. Number assigned to the quasar used. Unsigne d Integer –2 N/A 0 to 216-1
data_qual_flag 40 Data quality flag. 0 => good 1 => poor Unsigne d Integer –1 N/A 0 or 1
freq_chan_num 41 Frequency channel number. Valid only if rec_type is 71 or 72. Unsigne d Integer –1 N/A 0 to 255
mode_id 42 Mode identifier. Valid only if rec_type is 73; equals 0 otherwise. 0 => one-way 1 => two-way Unsigne d Integer –1 N/A 0 or 1
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
modulo_flag 43 Modulo flag. Valid only if rec_type is 73 or 74. Unsigne d Integer –1 N/A 0 or 1
0 => modded
1 => unmodded
ref_freq 44 Reference frequency. IEEE Double Hz / 1 mHz 1.0e9 to 4.0e9
modulus 52 Modulus. Valid only if rec_type is 73 or 74. IEEE Double nsec / 0.1 psec 0.0 to 100,000. 0
dod_cnt_time 60 Count time for VLBI delay rate observable. IEEE Single Seconds / 0.1 sec 0.0 to 100,000. 0
dod_obs 64 VLBI delay rate observable. IEEE Double Hz / 10-6 Hz -1.0e6 to 1.0e6
dor_obs 72 VLBI delay observable. IEEE Double nsec / 0.1 psec -1.0e9 to 1.0e9
Reserve20 80 Reserved. Twenty bytes. Unsigne d Integer –20 N/A 0
3.1.5.5 Filtered Data CHDOs

There are two filtered data CHDOs: Smoothed Noise (data type 12) and Allan Deviation (data type 13). Their formats and contents are specified in sections 3.1.5.5.1 to 3.1.5.5.2.

3.1.5.5.1 Smoothed Noise CHDO (Data Type 12)

The Smoothed Noise CHDO is generated for UPL-DTT antennas only and is defined in Table 3-25. Not generated if predicted frequencies are not available.

Table 3-25. Smoothed Noise CHDO (Data Type 12) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the smoothed noise data CHDO. CHDO contains binary data. Unsigne d Integer –2 N/A 10
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_length 2 Length attribute of the smoothed noise data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 46
01sec_sm_noise 4 0.1-second smoothed noise IEEE Hz / 0.0 to 47
measurement. Single 0.1 Hz 1000.0
1sec_sm_noise 8 1-second smoothed noise measurement. IEEE Single Hz / 0.1 Hz 0.0 to 1000.0 47
10sec_sm_noise 12 10-second smoothed noise measurement. IEEE Single Hz / 0.1 Hz 0.0 to 1000.0 47
100sec_sm_noise 16 100-second smoothed noise measurement. IEEE Single Hz / 0.1 Hz 0.0 to 1000.0 47
200sec_sm_noise 20 200-second smoothed noise measurement. IEEE Single Hz / 0.1 Hz 0.0 to 1000.0 47
600sec_sm_noise 24 600-second smoothed noise measurement. IEEE Single Hz / 0.1 Hz 0.0 to 1000.0 47
int_time 28 Integration time. Total integration time of measurements. Unsigne d Integer –4 Seconds / 1 sec 1 to 10,800
percent_data_used 32 Percent of data used. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 50
new_01sec 36 0.1-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 48
new_1sec 37 1-second measurement is new. Unsigne d N/A 0 or 1 48
0 => Old data 1 => New data Integer1
new_10sec 38 10-second measurement is new. Unsigne d N/A 0 or 1 48
0 => Old data 1 => New data Integer1
new_100sec 39 100-second measurement is new. Unsigne d N/A 0 or 1 48
0 => Old data 1 => New data Integer1
new_200sec 40 200-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 48
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
new_600sec 41 600-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 48
reserve8 42 Reserved. Eight bytes. Unsigne d Integer –8 N/A 0
3.1.5.5.2 Allan Deviation CHDO (Data Type 13)

The Allan Deviation CHDO is generated for UPL-DTT antennas only and is defined in Table 3-26. Not generated if predicted frequencies are not available.

Table 3-26. Allan Deviation CHDO (Data Type 13) Definitions

Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
chdo_type 0 Type attribute of the Allan Deviation data CHDO. CHDO contains binary data. Unsigned Integer – 2 N/A 10
chdo_length 2 Length attribute of the Allan Deviation data CHDO value field. Number of bytes after this item. Unsigne d Integer –2 bytes 42
01sec_allan_dev 4 0.1-second Allan Deviation measurement. IEEE Single Unitless 0.0 to 1.0 49
1sec_allan_dev 8 1-second Allan Deviation measurement. IEEE Single Unitless 0.0 to 1.0 49
10sec_allan_dev 12 10-second Allan Deviation measurement. IEEE Single Unitless 0.0 to 1.0 49
100sec_allan_dev 16 100-second Allan Deviation IEEE Unitless 0.0 to 49
measurement. Single 1.0
1000sec_allan _dev 20 1000-second Allan Deviation measurement. IEEE Single Unitless 0.0 to 1.0 49
int_time 24 Integration time. Unsigne d Integer –4 Seconds / 1 sec 1 to 106
percent_data_used 28 Percent of data used. IEEE Single Percentage / 0.1 percent 0.0 to 100.0 50
Identifier Byte Offset Item Name and Description Format Units/ Precision Range Notes
rpt_cause 32 Cause of report generation. 0 => 1000 second report 1 => Doppler mode change 2 => Idle mode Unsigne d Integer –1 N/A 0 to 2
new_01sec 33 0.1-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 51
new_1sec 34 1-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 51
new_10sec 35 10-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 51
new_100sec 36 100-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 51
new_1000sec 37 1000-second measurement is new. 0 => Old data 1 => New data Unsigne d Integer1 N/A 0 or 1 51
reserve8 38 Reserved. Eight bytes. Unsigne d Integer –8 N/A 0

3.2 Dependencies

None identified.

Appendix A Notes

  1. Seconds to HH:MM:SS (UTC) format:

    0.0 => 00:00:00
    86399.0 => 23:59:59
    86400.0 => Leap second

  2. This offset (transmit_time_tag_delay) should be added to the time tag. It is used to compensate for differences in the time tag point and the antenna radiation point.

  3. This offset (rcv_time_tag_delay) should be subtracted from the time tag. It is used to compensate for differences in the time tag point and the antenna radiation point.

  4. Array delay (array_delay) is included in the station calibration value (stn_cal) measurement and should be subtracted from the time tag.

  5. Spacecraft transponder lock (scft_transpd_lock), spacecraft transponder number (scft_transpd_num), spacecraft two-way non-coherent (TWNC) status (scft_twnc_stat), and spacecraft oscillator type (scft_osc_type) are obtained from spacecraft engineering data, which may not be available.

  6. Spacecraft oscillator frequency (scft_osc_freq) is obtained from spacecraft project supplied data.

  7. Spacecraft transponder delay (scft_transpd_delay) is based on spacecraft and configuration data supplied from spacecraft project. In the future, it may be based on engineering data from the spacecraft. This is the delay the ranging signal experiences through the spacecraft.

  8. PHASE = HI * 232 + LO + FRAC * 2-32 ,

    where,

    HI = ul_hi_phs_cycles, or phs_hi_x (with x = 0 through 9), phs_hi_avg, or dop_cnt_hi, or total_cnt_phs_ob_hi

    LO = ul_lo_phs_cycles, or phs_lo_x (with x = 0 through 9), or phs_lo_avg, or dop_cnt_lo, or total_cnt_phs_obs_lo

    FRAC = ul_frac_phs_cycles, or phs_frac_x (with x = 0 through 9), or phs_frac_avg, or dop_cnt_frac, or total_cnt_phs_obs_frac


  9. If LNA number (lna_num) as reported at the station is unknown or invalid (e.g., 0), then the default LNA number may be used (i.e., lna_corr_value). LNA number, or when necessary the LNA correction value, is used to determine dl_zheight_corr (see note 60), which is subsequently used to formulate the range observable (i.e., rng_obs, see note 39). If lna_corr_value is reported as zero, then this value is not used.

  10. If hardware at station allows splitting the uplink and downlink ranging delays, thevalue will be included here. Otherwise, it is set to 0.0.

  11. Measured code value (ul_rng_phs) and measured range value (dl_rng_phs) are the phase of the ranging signal at the time tag.

  12. T1 setting (t1) is the length of time that the first component (the clock) is transmitted.

  13. T2 setting (t2) is the length of time that each subsequent component is transmitted.

  14. T3 setting (t3) is the length of time that the clock is transmitted for each DRVID measurement.

  15. Component frequency is F_EXC * 2-(n+2), where n is the component number and F_EXC is the exciter reference signal (see note 17).

  16. Chopping modulates the ranging signal with a subcarrier at the chop component frequency (chop_comp_num), for all components after and including the chop start component (chop_start_num). For example, if the chop start component value is 6 and the chop component is 5, all components from 6 on will be modulated with component 5. If the chop value is zero, all components starting with 15 and larger are chopped with the clock component.

  17. The exciter reference frequency (F_EXC) is defined as follows:

    F_EXC = FRQ_UP * (exc_scalar_num/exc_scalar_den)

    Where FRQ_UP is the uplink carrier frequency.


  18. Sequential ranging cycle time is defined as follows:

    rng_cycle_time = (t1 + 2) + (last_comp_num – first_comp_num) * (t2 + 1) + num_drvid * (t3 + 2) + 1

  19. The PN ranging code is a combination of multiple sequences logically combined. The code state is the particular bit (or chip) in the sequence, plus the phase of that chip at the time tag. For a component length L, and a subsequence state S, the code state C is related to L and S by:

    S = C mod L


  20. PN chip rate = F_EXC / clk_divider

  21. The first “n” bits (where n is the length specified in len_seqj) define the PN subsequence, e.g., a value of 46 for def_seq4 gives the following sequence: 0101110, which will have a value of 7 in len_seq4.

  22. Code length (pn_code_length) equals the result of multiplying the lengths of all of the subsequences together.

  23. PN cycle time is 16 * clk_divider * pn_code_length.

  24. One Range Unit (RU) is defined as:

    1 RU = (exc_scalar_den / exc_scalar_num) / (16 * FRQ_UP)

    Where FRQ_UP is the uplink carrier frequency. Range is measured in RU to give a stable reference measurement when the uplink is being ramped.


  25. If carrier is suppressed (carr_resid_wt = 0.0), then the data power is used for the carrier tracking.

  26. Doppler noise (dop_noise) is the standard deviation of the detrended downlink frequency residuals. The detrending is the removal of the least squares linear fit of the frequency residuals over the sample period. For the Downlink Carrier Phase data type (data type 1) and Doppler data type (data type 6), the sample period is 1 second. For the Carrier observable data type (data type 16), the sample period is sample integration time (obs_cnt_time) times the number of samples (num_obs). The equation for the Doppler noise is (F is the frequency residual, FL is the linear least squares fit of F, and t is the spacing between points): >

  27. carr_resid_wt is the weight value applied to residual phase error in carrier tracking; suppressed carrier weight is 1.0 minus this value, e.g.,

    φerr = carr_resid_wt * φerr_resid + (1 – carr_resid_wt) * φerr_suppressed



  28. Figure of Merit (FOM) (figure_merit) is the estimate of the probability of successfully acquiring all of the lower components (other than the clock component). It is expressed as a percentage (0.0 to 100.0). For sequential ranging, it is defined as:

    Where Erf(*) is the error function.

    For PN ranging, it is defined as:

    Where, Cmin and Cmax are the minimum and maximum correlation value for each subsequence and LEN(I) is the length of the ith subsequence (2, 7, 11, 15, 19, and 23).

  29. Range residual accuracy depends on the accuracy of the predicts and is rarely better than 1 μsec (1000 RU).

  30. DRVID (drvid) stands for Differenced Range Versus Integrated Doppler. It is a measurement of the difference between the group and phase delay of the media. The measurement (at time tag TT) is the difference between two consecutive measured range points (i.e., points separated by the cycle time) minus the scaled difference in the uplink and downlink carrier phases over the same time period. The measurement is defined below:

    D_RNG = (meas_rng(TT) – meas_rng(TT-rng_cycle_time)), mod rng_modulo

    I_DOP = {(φT(TT) -φT(TT – rng_cycle_time)) –
    (scft_transpd_turn_den / scft_transpd_turn_num) *
    (φR(TT) -φR(TT – rng_cycle_time))}

    drvid = D_RNG – [16 * (exc_scalar_num / exc_scalar_den) * I_DOP mod rng_modulo]

    This has previously been called pseudo-DRVID, since the measurement does not require increasing the cycle time by adding additional clock transmissions during the measurement. The method of using additional clock cycles does not measure the carrier phase over the same period of time as the range measurement; this is why the pseudo-DRVID implementation was selected.

  31. Slipped cycles (slipped_cycles) are estimated by processing the frequency residuals in a software-simulated, digital phase-locked loop and comparing the phase error with slip conditions. This estimate is subject to degradation during high noise conditions. The slipped cycles value is the number of cycle slips (both positive and negative) detected in this manner, for the sample interval.

  32. Delta Frequency/Frequency (delta_ff) is the change in downlink frequency since the last sample, divided by the downlink frequency at this time tag.

  33. A set of measurements is provided in the Received Carrier and Total Count Phase Observables data types (data types 16 and 17). For each set, a number of measurements (num_obs) and a time interval (obs_cnt_time) are provided. The first measurement is at the time tag reported in the header; the ith measurement (i = 1 to number of measurements) is at the time tag (TT) plus (i-1) * obs_cnt_time. The interval of time covered by the measurements is TT – obs_cnt_time to TT + (number of measurements – 1)* obs_cnt_time.

  34. The Doppler Count is defined as difference in the downlink carrier phase plus a bias term (generated by integrating dop_cnt_bias_freq) minus the uplink carrier phase (generated by integrating ul_freq)scaled by the spacecraft transponder turn around ratio.. The bias term is used to keep the Doppler Count a positive value. The time tag is the end of the Doppler Count interval.

    Doppler Count = (φR,i ) + ((scft_transpd_turn_num/scft_transpd_turn_den) * -ul_freq+ dop_cnt_bias_freq )* (TimeI – Timestart)



  35. The Received Carrier Frequency Observable is defined as the negative of the difference in the downlink phase at the end of the interval and the downlink phase at the start of the interval, divided by the interval time. The time tag point of the difference is the middle point of the count time interval (note that this means that the time tag may be on the half second). The time tag of the ith measurement (i equals 1 to num_obs) is TT + (i – 1.0) * obs_cnt_time.

    Observable = - (φi -φi-1) / obs_cnt_time



  36. The Total Count Phase Observable is the difference between the downlink carrier phase at the measurement time tag and the downlink carrier phase at a starting point (a running integration). The time of the starting point is given by total_cnt_phs_st_year, total_cnt_phs_st_doy, and total_cnt_phs_st_sec. The starting point changes whenever something causes the carrier lock to be broken, such as spacecraft mode changes or downlink loss of lock. The time tag of the ith measurement (i equals 1 to num_obs) is TT + (i - 1) * obs_cnt_time.

    Observable = - (φi -φstart)

    The value reported is the negative of the observable, e.g.:

    Reported Observable = (φi -φstart)

  37. Sequential ranging ambiguity (rng_modulo) in Range Units is defined as

    26+last_comp_num.



  38. Sequential measured range (meas_rng) is the difference between the uplink ranging phase (ul_rng_phs) and the downlink ranging phase (dl_rng_phs) (for UPL-DTT antennas). For non-UPL-DTT antennas, the Sequential Ranging Assembly range value is used. The difference is the positive modulo of rng_modulo value. This measurement is not corrected for any calibration issues.

  39. Range Observable is defined as the measured range (meas_rng) minus the calibration correction. This observable is valid for both UPL-DTT and non-UPLDTT antennas and is supplied to maintain compatibility between the two. The calibration correction is defined as:

    Correction = (ul_stn_cal – transmit_time_tag_delay) + ul_zheight_corr + scft_transpd_delay + (dl_stn_cal – rcv_time_tag_delay – array_delay) + dl_zheight_corr

  40. If the measured uplink calibration value (ul_stn_cal) as reported in the uplink range SFDUs is non-zero, then the uplink calibration value (ul_stn_cal) in the derived SFDUs for sequential and PN range is this value. Otherwise, it is one-half of the station calibration value (stn_cal). If the value is invalid, the parameter is set to –1.0.

  41. If the measured downlink calibration value (dl_stn_cal) as reported in the downlink ranging SFDUs is non-zero, then the downlink calibration value (dl_stn_cal) in the derived SFDUs for sequential and PN range is this value. Otherwise, it is one-half of the station calibration value (stn_cal). ). If the value is invalid, the parameter is set to –1.0.

  42. The uplink frequency (ul_freq) is provided for computing the Range Unit definition for those antennas that do not support ramped uplinks (i.e., no Data Type 9).

  43. Range noise (rng_noise) is the standard deviation of up to the last 100 (i.e., if more than 100 data points exist, only the last 100 are used) range residuals, detrended by removing the least squares linear fit of the data. The equation for the Range noise is (R is the range residual, RL is the linear least squares fit of R, N is the number of points (up to 100), and t is the spacing between points):

  44. DRVID noise (drvid_noise) is the standard deviation of up to the last 200 (i.e., if more than 200 data points exist, only the last 200 are used) DRVID values. The equation for the DRVID noise is (D is the DRVID residual, N is the number of points (up to 200), and t is the spacing between points):



  45. PN ranging ambiguity (modulo value) is defined as:

    rng_modulo = 16 * clk_divider * pn_code_length



  46. PN measured range value (meas_rng) is the difference between the uplink ranging phase (ul_rng_phs) and the downlink ranging phase (dl_rng_phs). It is only available from the UPL-DTT antennas. The difference is the positive modulo of the rng_modulo value. This measurement is not corrected for any calibration issues.

  47. Smoothed noise is the standard deviation of the detrended downlink frequency residuals. The detrending is the removal of the least squares linear fit of the frequency residuals over the sample period. Estimates are computed for 0.1, 1, 10, 100, 200, and 600-second intervals. The minimum sample period is 180 seconds, the maximum is 10,800. The standard deviation is computed over 18 points; if the number of points in the reporting period is more than 18 (e.g., 0.1-second and 1.0-second), the 18-sample standard deviations are averaged. The equation for the Smoothed noise is (F is the frequency residual, FL is the linear least squares fit of F, and t is the time spacing between points):

  48. Since the record is generated every 180 seconds and each integration needs 18 points, the longer integrations will not be updated every time. The new_xxx flags are used to indicate which integrations have been updated.

  49. Allan deviation is computed for interval (τ) values of 0.1, 1, 10, 100, and 1000 seconds. The record is nominally output once every 1000 seconds. The frequency residuals are used for the computation (to remove the known motion effects, such as earth rotation). The result is normalized to DSN channel 14 (2295 MHz for S-band, 8415 MHz for X-band, and 31.977 GHz for Ka-band); this value is referred to as F0. The number of points, N, is equal to the integration time, INT_TIME, divided by τ.

  50. percent_data_used indicates if some data in the integration period was not used (e.g., carrier was out of lock).

  51. If a record is generated due to a change in system status (e.g., receiver mode change), the report time will be short of the normal 1000 seconds, so the longer integrations may not have a new point computed. The new_xxx flags are used to indicate which integrations have been updated.

  52. Some hardware (ground or spacecraft) may invert the ranging modulation. invert allows these inversions to be corrected on the uplink or downlink processing.

  53. Loop Type (carr_loop_type) is the number of poles in the carrier phase locked loop transfer function. The number poles (or order) of the loop filter is the Loop Type minus one. For each increment in the Loop Type, one higher order derivative of Doppler is tracked out to zero (Type 1 tracks out phase offsets, Type 2 tracks out frequency errors, Type 3 tracks out frequency rate errors).

  54. The time offset (prdx_time_offset) is a value added to the current time when generating the predicted frequency from the frequency predicts (F(t)). Thus, the predicted frequency (F_PRED), at time t, used by the tracking loop is:

    F_PRED = F(t + prdx_time_offset)



  55. The frequency offset (prdx_freq_offset) is a value added to the frequency value generated from the frequency predicts (F(t)). Thus, the predicted frequency (F_PRED), at time t, used by the tracking loop is:

    F_PRED = F(t) + prdx_freq_offset

  56. Correlation validity (correl_vld_flag) is reported by the downlink ranging equipment. It is an estimate of whether or not the clock component is properly aligned with the received ranging signal (it measures the power in the inphase and quadrature signals when correlating the lower components – if the clock is properly aligned, the power in the inphase signal is much greater than the quadrature signal).

  57. The Angles Validity Flag (ang_vld_flag) is set by the tracking equipment to indicate whether or not the angle data is valid.

  58. The signal level (rcv_sig_lvl) is either provided by the tracking station (non-UPLDTT antennas), or derived from other parameters (UPL-DTT antennas). For the 34m and 70m antennas, the derivation is as follows:

    Signal Level = P_N0 – (K_DB + 10 * log10(system_noise_temp))

    Where K_DB is Boltzmann’s constant (-198.6 dBm/Hz/k), system_noise_temp is the system noise temperature, and P_N0 is either pcn0 (car_resid_wt > 0.0) or pdn0 (car_resid_wt = 0.0).



  59. The In Phase Time (transmit_inphs_time or rcv_inphs_time) is the time point that the ranging modulation reference was initialized to zero phase. It is used for three-way ranging cases. It is seconds of day offset from the block time tag.

  60. Distance (in time) to the phase center of the antenna that is not included in the station calibration. Included in this value is the delay to and from the test translator, the delay inside the test translator, the delay from the range calibration coupler to the phase center of the antenna, and the delay between the main antenna dish and the subreflector. Z-height is expressed in seconds, so it must be converted to Range Units before it is included in the Range Observables. The uplink part of this compensation (which is the delay from the point that the test translator taps off of the uplink path to the phase center) is provided in ul_zheight_corr and the downlink part (which is the delay from the phase center to the point where the test translator joins the downlink path, minus the delay of the test translator path) is in dl_zheight_corr.

  61. When downlink carrier data is received, it reports the configuration that was used at the tracking station for the source of the downlink (e.g., three-way with DSS 65). However, that may not be the actual spacecraft mode (for example, the spacecraft may have been locked to an uplink from DSS 54, but the receiving station did not have any three-way predicts for DSS 54, so the predicts for DSS 65 were used instead). A validation is done to determine the actual spacecraft mode and is reported in the validated uplink station (nk station (vld_ul_stn) and validated doppler mode (vld_dop_mode) fields of the downlink data secondary CHDO.

  62. The Carrier and Total Phase Count Pre-fit Residual Tolerance flags (carr_prefit_resid_tol_flag and total_phs_cnt_prefit_resid_tol_flag) indicate whether or not the pre-fit residuals are within the tolerance (carr_prefit_resid_tol_value and total_phs_cnt_prefit_resid_tol_value) set by the spacecraft project. The prefit residual flags (carr_prefit_resid_tol_flag and totalfit_resid_tol_flag) are set to Not Applicable if the prefit residual validity flags (carr_prefit_resid_vld_flag and total_phs_cnt_prefit_resid_vld_flag) indicate invalid.

  63. The Range Residual Tolerance flag (rng_resid_tol_flag) indicates whether or not the range residual is within the tolerance (rng_resid_tol_value) set by the spacecraft project.

  64. The DRVID Tolerance flag (drvid_tol_flag) indicates whether or not the DRVID value is within the tolerance (drvid_tol_value) set by the spacecraft project.

  65. The Pr/N0 Residual Tolerance flag (prn0_resid_tol_flag) indicates whether or not the Pr/N0 residual is within the tolerance (prn0_resid_tol_value) set by the spacecraft project.

  66. The Range Sigma Tolerance flag (rng_sigma_tol_flag) indicates whether or not the range sigma (noise) is within the tolerance (rng_sigma_tol_value) set by the spacecraft project.

  67. The Range Validity flag (rng_vld_flag) indicates that the range data is valid if the receiver is in-lock, if the Correlation Validity flag (correl_vld_flag) indicates valid data, and the FOM (figure_merit) is above its tolerance value (fom_tol_value). Additionally, for the derived data types (Data Types 7 and 14), the condition of the data not being calibration data (rng_meas_type) is also included.

  68. The Range Configuration Change flag (rng_config_flag) is set whenever the system determines the microwave configuration has changed since the ranging calibration was done.

  69. Note 69 has been deleted.

  70. The Metrics Validity flag (metrics_vld_flag) indicates whether or not the downlink ranging equipment was able to process the ranging data to get a measurement of range and DRVID (for example, the pass may have been three-way and the uplink data was not available).

  71. Note 71 has been deleted.

  72. Currently, the equipment that performs the tone range measurement includes the corrections for the calibration and the Z-height correction in the reported range; however, these values are not reported by the station. Thus, stn_cal, ul_zheight_corr, dl_zheight_corr are set to 0.0. The range observable (rng_obs) is equal to meas_rng minus the spacecraft transponder delay scft_transpd_delay. If the equipment at the station is corrected, the values will be non-zero.

  73. The Modification Time items (day and msec) are set to 0 when the block is first created. If any data in the block is changed, the items are set to the time of the modification. The time is expressed as the time (UTC) since the epoch of January 1, 1958. The time is represented as days since the epoch and milliseconds of the day.


  74. The record creation time is the time when the data processing task first creates the record. It is expressed as the time (UTC) since the epoch of January 1, 1958. The time is represented as days since the epoch and milli-seconds of the day.

  75. The In Phase Time (transmit_inphs_time_xxx or rcv_inphs_time_xxx, where xxx is year, doy, or sec) is the time point (UTC) that the ranging modulation reference was initialized to zero phase. It is used for three-way ranging cases. When reported from the DSN stations, it is reported as an absolute time (see note 59 regarding its other format).

  76. The Downlink Range Observable (rng_obs_dl) is defined as the calibration correction minus the downlink ranging phase. It is only valid for UPL-DTT antennas. The calibration correction is defined as:

    Correction = (ul_stn_cal – transmit_time_tag_delay) + ul_zheight_corr + scft_transpd_delay + (dl_stn_cal – rcv_time_tag_delay – array_delay) + dl_zheight_corr



  77. Downlink range observable validity flag (rng_obs_dl_vld_flag) indicates whether or not the Downlink range observable item (rng_obs_dl) is valid. It will be invalid if the data is for a non-UPL-DTT antenna.

  78. The Clock Offset Epoch Time (clk_off_epoch_year, clk_off_epoch_doy, and clk_off_epoch_sec) is the time (UTC) that the two clock offsets (clk_off_1 and clk_off_2) where measured .

  79. The uplink data is only valid if the validated spacecraft coherency (vld_scft_coh) indicates an uplink (value of 1 or 3).

  80. Note 80 has been deleted.

  81. This computation is done at the station. The metrics validity flag (metrics_vld_flag) indicates its validity.

  82. For DTT data, the downlink band is assumed to be correct. For non-DTT data, a validation is done. In the case of 26m stations, which use the two acquisition aid antennas (for both S- and X-band), if the downlink band cannot be definitively determined, the value gets set to "S or X".

  83. The carrier lock status (carr_lock_stat) for non-DTT antennas is inferred from other values.

  84. The count time (interval), Tc, that is used to form an observable is constrained by the sample interval.

  85. Note 85 has been deleted.

  86. Until prefit residual values (rng_dl_prefit_resid, rng_prefit_resid, and carr_prefit_resid) are delivered, they will be indicated as invalid by setting their residual flags (rng_dl_prefit_resid_vld_flag, rng_prefit_resid_vld_flag, and carr_prefit_resid_vld_flag, respectively) to a value of 0.

  87. Arraying is done using the Full Spectrum Processor (FSP). There are two FSPs per complex.

  88. This field only pertains to the Doppler (Data Type 6), the Received Carrier Frequency Observables (Data Type 16) and the Total-Count Phase Observables (Data Type 17) data CHDOs. Otherwise, when not applicable, the field is set to 0. In the case of Data Types 16 and 17, this field describes the compression interval, which ranges from 0.1 through 3600.0 seconds. In the case of Data Type 6, this field describes the sample interval. 26m stations are capable of producing tracking data at sample intervals of 0.1, 1, 10, or 60 seconds. UPL/DTT stations produce tracking data at a 0.1 second interval.

  89. The Doppler Validity Flag (dop_vld_flag) is set by the tracking equipment to indicate whether or not the doppler data is valid.

Appendix B File Format

B.1 LVO Structure of Files

When the data defined by this document are stored in a file, the file is wrapped with an attached header. The file consists of nested LVOs, including a catalog LVO (known as the K-object LVO) and a data LVO (known as the I-object LVO). The catalog LVO contains the meta-data needed to catalog the actual tracking data. The data LVO consists of CHDO SFDUs defined in Section 3. The LVO structure of a file is depicted in Figure B-1. Further details on the contents of the label and value fields of each LVO are provided in the following subsections.

Figure B-1. LVO Structure of Files

B.2. Physical Layout of Files

The physical layout of the TRK-2-34 file is shown in Figure B-2. The length in bytes is 88+M+L, where M is the length of the catalog field and L is the length of the CHDO SFDUs. The structure is divided into three main parts:

  • primary label of the entire SFDU (Table B-1 describes the primary label.)

  • K-header. The K-header (or K-object) consists of the K-header SFDU label (or K-object SFDU label), catalog information, and an end marker. The catalog information consists of meta-data for cataloging the SFDU file. The meta-data are in the form of keyword-value pairs (hence, the “K” for keyword). (Tables B-2 and B-3 describe the K-header.)

  • I-object. The I-object (where “I” stands for information) contains the CHDO SFDUs defined by Section 3, preceded by an I-object SFDU label. (Table B-4 describes the I-object SFDU label.)

Figure B-2. File Layout

See Figure B-3 for a sample header of a TRK-2-34 file.

CCSD3ZF0000100000001NJPL3KS0PDSX$T-2-34$
PDS_VERSION_ID = PDS3
RECORD_TYPE = UNDEFINED
MISSION_NAME = CASSINI
SPACECRAFT_NAME = CASSINI
SPACECRAFT_ID = 82
MISSION_ID = 7
DATA_SET_ID = TRK234
FILE_NAME = 013610115SC82DSS65.234
PRODUCER_ID = TDDS
PRODUCT_CREATION_TIME = 2001-361T23:59:59
START_TIME = 2001-361T01:15:10
STOP_TIME = 2001-361T12:30:30
INTERCHANGE_FORMAT = BINARY
NOTE = “Carrier lock status in DT1 changed by Jane Doe.”
CCSD$$MARKER$T-2-34$NJPL3IF0T23400000001



Figure B-3. Sample Header of File

B.2.1. Primary SFDU Label

Bytes 0 through 19 of the tracking SFDU file contain the primary SFDU label field for the files. The format and content of the label are defined in Table B-1.

Table B-1. Primary SFDU Label

Byte

Data Item.
Description and Units.

Format Range
0 to 3 Control authority identifier (CAID). This CAID field indicates that the data description information (referred to in bytes 8 to 11) for this SFDU is maintained and disseminated by the CCSDS control authority. Control authority identifiers are assigned by the CCSDS. Restricted ASCII-4 ‘CCSD’
4 SFDU version identifier. This version field indicates how this primary SFDU label is delimited. The value of ‘3’ indicates that this LVO can be delimited by marker, EOF (end of file), or length. Restricted ASCII-1 ‘3’
5 SFDU class identifier. This class identifier field gives a high-level classification of the content of the value field of this LVO (i.e., this TRK-2-34 LVO that contains the K-header LVO and the I-object LVO). The value of ‘Z’ indicates that the value (V) field of this LVO contains a JPL LVO with a CCSD CAID. Restricted ASCII-1 ‘Z’
6 Delimiter identifier. This delimitation identifier indicates the type of delimiter this primary SFDU label uses for its last eight bytes. A value of ‘F’ indicates this label ends with ‘00000001’, as specified in bytes 12 to 19, which implies that the entire SFDU is closed with an EOF marker. Restricted ASCII-1 ‘F’
7 Reserved. This byte is a spare field. Restricted ASCII-1 ‘0’
8 to 11 Data description package identifier. This field uniquely identifies (for the specified Control Authority, i.e., CCSDS, per bytes 0 to 3) the package that contains the definition of the data object [or value (V) field of this LVO]. The value shown here is registered with the specified control authority. Restricted ASCII-4 ‘0001’
12 to 19 Length attribute of the SFDU. This field is designated the “length” field because data are delimited by length for stream data. However, since this SFDU is considered to be a file SFDU, rather than a stream SFDU, the end of the TRK-2-34 LVO (SFDU) is designated by an EOF marker. The EOF marker is specified in this primary SFDU label as ‘00000001.’ Standard ASCII-8 ‘0000000 1’

B.2.2 K-Header (or K-Object)

Bytes 20 to 59+M are the K-header (or K-Object) for the file (M is the length of the catalog information, which is variable length). The three components of the K-header are described below.

B.2.2.1 K-Header SFDU Label

Bytes 20 to 39 are the label field for the K-Header SFDU (or Catalog LVO) for the files. The 20 bytes of the label field are defined below in Table B-2.

Table B-2. K-Header (or K-Object) SFDU Label

Byte Data Item.
Description and Units. 		Format Range
0 to 3 Control authority identifier (CAID). This CAID field indicates that the data description information (referred to at bytes 8 to 11) for this SFDU is maintained and disseminated by the NASA/JPL control authority. Restricted ASCII-4 ‘NJPL’
4 SFDU version identifier. This version field indicates how this K-header SFDU label is delimited. The value of ‘3’ indicates that this LVO can be delimited by marker, EOF (end of file), or length. In this case, the actual delimiter is by marker, as indicated by byte 6. Restricted ASCII-1 ‘3’
5 SFDU class identifier. This class identifier field gives a high-level classification of the content of the value field of this LVO (i.e., the K-header LVO). The value of ‘K’ indicates that the value (V) field of this LVO contains a K-header. [The K-header contains metadata that describes the I-object LVO (information or data object) that follows it.] Restricted ASCII-1 ‘K’
6 Delimiter identifier. This delimitation identifier indicates the type of delimiter this K-header SFDU label uses for its last eight bytes. A value of ‘S’ indicates that this label ends with a marker, i.e., a start marker (signifying the start of the value field). [The value (V) field of the K-header LVO is the Catalog information. It is delimited by a start marker at the end of this K-header SFDU label, and then by a matching end marker at the end of the value (V) field.] The marker is specified in the ‘Length attribute’ field of this label at bytes 12 to 19. Restricted ASCII-1 ‘S’
7 Reserved. This byte is a spare field. Restricted ASCII-1 ‘0’
8 to 11 Data description package identifier. This field uniquely identifies (for the specified Control Authority, i.e., NJPL, per bytes 0 to 3) the data object [or value (V) field of this LVO]. The value shown here is registered with the specified control authority. Restricted ASCII-4 ‘PDSX’
12 to 19 Length attribute of the SFDU. The Catalog information is delimited with a start and end marker. Standard ASCII-8 ‘$T-234$’
B.2.2.2 Catalog Information

The catalog information for the files starts at byte 40 and is defined below in Table B-3. This value field of the LVO contains the set of parameters and values, in <keyword/parameter>=<value> format, of attributes that are pertinent to the file data. Each line is terminated with a carriage return (ASCII decimal code 13, written as <CR> or Ctrl-M), and a line feed (ASCII decimal code 10, written as <LF> or Ctrl-J). The values must conform to the standard ASCII character set (32 through 127 decimal). In addition, the values should be in upper case, except for the NOTE field.

Table B-3. Catalog Information (Value Field of the K-Object)

Ref # Keyword-Value Pairs.
Description and Units. 		Range for Value
1 PDS_VERSION_ID = <value><CR><LF> Represents the version number of the standards document that is valid when the label is created. ‘PDS3’
2 RECORD_TYPE = <value><CR><LF> The record format of this file. ‘UNDEFINE D’
3 MISSION_NAME = <value><CR><LF> The name of the mission or project that is associated with the data contained in the I-object. Must be upper case. Varies
4 SPACECRAFT_NAME = <value><CR><LF> The full, unabbreviated name of the spacecraft that is associated with the data contained in the I-object. Must be upper case. Varies
5 SPACECRAFT_ID = <value><CR><LF> The decimal representation of the applicable DSN spacecraft number as defined in Reference [3a]. ‘0’ thru ‘255’
6 MISSION_ID = <value><CR><LF> The decimal representation of the applicable DSN mission number per Reference [3a]. ‘0’ thru ‘255’
7 DATA_SET_ID = <value><CR><LF> The unique identifier for this data type. ‘TRK234 ‘
8 FILE_NAME = <value><CR><LF> The unique file name, without a directory path specified, for this SFDU file. The file name shall be of the form: yydddhhmmSCsssssDSSnnnnn.234, where, yy is the two-digit year ddd is the three-digit day-of-year (001 thru 366) hh is the two-digit hour into the day (00 thru 23) mm is minutes into the hour (00 thru 59) SC is fixed, and denotes that the spacecraft ID is to follow: sssss is the spacecraft ID (per Reference [3a], with leading zeros omitted) DSS is fixed, and denotes that the DSS ID is to follow: nnnnn is the DSS ID (per Reference [8], with leading zeros omitted) . 234 is a fixed suffix, and identifies the file as being a TRK-2-34 file. The time reflects the time of the latest tracking sample (or “cutoff “ time) contained in the file. Varies
9 PRODUCER_ID = <value><CR><LF> A short name or acronym for the producer or producing team/group (e.g., TDDS) of this file. An ASCII character string, limited to 20 characters (must be upper case). Varies
10 PRODUCT_CREATION_TIME = <value><CR><LF> This attribute indicates the UTC time at which this file was created. The value is specified in the following time format: yyyy-dddThh:mm:ss where, yyyy four-digit year ddd day-of-year (001 thru 366) T ASCII literal field (i.e., “T”) hh hours of the day (00 thru 23) mm minutes of the hour (00 thru 59) ss seconds of the minute (00 thru 60), allows for leap second any valid UTC
11 START_TIME = <value><CR><LF> This attribute identifies the earliest time tag (in UTC) reported across all SFDU secondary CHDOs included in the data object. The value is specified in the following time format: yyyy-dddThh:mm:ss where, yyyy four-digit year ddd day-of-year (001 thru 366) T ASCII literal field (i.e., “T”) hh hours of the day (00 thru 23) mm minutes of the hour (00 thru 59) ss seconds of the minute (00 thru 60), allows for leap second any valid UTC
12 STOP_TIME = <value><CR><LF> This attribute identifies the latest time tag (in UTC) reported across all SFDU secondary CHDOs included in the data object. The value is specified in the following time format: yyyy-dddThh:mm:ss where, yyyy four-digit year ddd day-of-year (001 thru 366) T ASCII literal field (i.e., “T”) hh hours of the day (00 thru 23) mm minutes of the hour (00 thru 59) ss seconds of the minute (00 thru 60), allows for leap second any valid UTC
13 INTERCHANGE_FORMAT = <value><CR><LF> Identifies the way the data object is stored. ‘BINARY”
14 NOTE = “<value>”<CR><LF> Description of changes made to the data in this TRK-2-34 file as a result of manual editing (may be upper or lower case). Varies

B. 2.2.3 K-Object End Marker

After the catalog information, starting at byte 40+M (M being the length of the catalog field), is the marker field. The marker field delimits the end of the catalog LVO. The 20 byte field is the following ASCII string:

“CCSD$$MARKER$T-2-34$”.

B.2.3 I-Object SFDU Label

Bytes 60+M to 79+M are the label field for the I-Object SFDU. The 20 bytes are defined below in Table B-4.

Table B-4. I-Object SFDU Label

Byte Data Item.
Description and Units. 		Format Range
0 to 3 Control authority identifier (CAID). This CAID field indicates that the data description information (referred to at bytes 8 to 11) for this SFDU is maintained and disseminated by the NASA/JPL control authority. Restricted ASCII-4 ‘NJPL’
4 SFDU version identifier. This version field indicates how this I-object SFDU label is delimited. The value of ‘3’ indicates that this LVO can be delimited by marker, EOF (end of file), or length. In this case, the actual delimiter is by EOF, as indicated by byte 6. Restricted ASCII-1 ‘3’
5 SFDU class identifier. This class identifier field gives a high-level classification of the content of the value field of this LVO (i.e., the I-object LVO). The value of ‘I’ indicates that the value (V) field of this LVO contains an I-object (or information object.) Restricted ASCII-1 ‘I’
6 Delimiter identifier. This delimitation identifier indicates the type of delimiter this I-object SFDU label uses for its last eight bytes. A value of ‘F’ indicates that this label ends with the value specified in bytes 12 to 19, which implies that the I-object ends with an EOF marker. Restricted ASCII-1 ‘F’
7 Reserved. This byte is a spare field. Restricted ASCII-1 ‘0’
8 to 11 Data description package identifier. This field uniquely identifies (for the specified Control Authority, i.e., NJPL, per bytes 0 to 3) the data object [or value (V) field of this LVO]. Restricted ASCII-4 ‘T234’
12 to 19 Length attribute of the SFDU. The end of this LVO is designated by marker — in this case, an EOF marker. The EOF marker is specified in this I-object SFDU label as ‘00000001.’ Note that the EOF marker terminating the I-object serves a dual purpose in that it also terminates the entire file, per bytes 12 to 19 of the primary SFDU label. Standard ASCII-8 ‘0000000 1’

B.2.4 Binary Data Object

Starting at byte 80+M (M being the length of the catalog field) is the binary data object. The binary data object of the file contains a series of CHDO SFDUs in time-sorted order. That is, given a file containing different data types, all the data types are interleaved based on time. The CHDOs are defined in Section 3. The total length of the binary data object is L bytes.

B.2.5 End of File (EOF)

Starting at byte 80+M+L (M being the length of the catalog field and L being the length of the binary data object) is the end of the file (EOF) marker. This 8 byte marker is defined in the Primary Label field, bytes 12 to 19. The value of the EOF marker is ‘00000001’.
